Attach lighting stick to the Right Rear Leg, below
side shelf bracket using 1 M4 x 10 self-tapping
screw.
Attach the 2 Bowl Brackets to Bowl Side Panel
using 4 of 1/4" x 1/2" Phillip Head Screw, 1/4" Nuts
and 1/4" Washers. Fully tighten. See Figure 5.
11.
1/4" x 1/2" Phillips Head Screw x 4
M4 x 10 Self-Tapping Screw x 1
1/4" Lock Nut x 4
12.
1/4" Washer x
4
13
