ASSEMBLY INSTRUCTIONS
STEP 13
26
Flame orifice
Ignition pin
Ignition wire
26 25
27
Insert the end of ignition wire to the ignition pin (26) on the right side burner bowl (25).
Note: manually adjust the gap between the ignition pin and the flame orifice around 3~5mm
(0.1 - 0.2inch) to ensure proper ignition.
