Grill Zone SRGG41207 - Step 14 & 15: Tray, Grates, and Rack Placement

19
ASSEMBLY INSTRUCTIONS
STEP 14
34
33
30
6
M5x12 bolts 2pcs
2
3
4
30
Fix grease tray (6) onto the grill body (30) with 2pcs M5 x 12 bolts; install grease cup (34) into
grease cup hanger (33) and then hang them onto the bottom of grease tray.
STEP 15
Place 4pcs flame tamers (4), 2pcs cooking grates (3) and 1pcs warming rack (2) into the grill body
(30) in turn.
