Description
Required for
assembly
Extra
hardware
Total
AA 5/32-in. x 10-mm Truss Head Screw
38 pcs. 2 pcs. 40 pcs.
BB 5/32-in. Locking Washer 36 pcs. 2 pcs. 38 pcs.
CC 1/4-in. x 15-mm Truss Head Screw
18 pcs. 2 pcs. 20 pcs.
DD 1/4-in. Locking Washer 26 pcs. 2 pcs. 28 pcs.
EE Tank Bolt 1 pc. -- 1 pc.
FF
Allen Key
1 pc. -- 1 pc.
GG
1/4-in. Axle Flat Washer 2 pcs. 1 pc. 3 pcs.
HH 1/4-in. Nut 2 pcs. 1 pc. 3 pcs.
II 5/32-in. Nut 3 pcs. 1 pc. 4 pcs.
JJ 1/4-in. x 61-mm Truss Head Screw
8 pcs. 1 pcs. 9 pcs.
KK 1/4-in. Flat Washer 14 pcs. 2 pcs. 16 pcs.
V. 1.5 Volt “AA” Size Alkaline
Battery----------1pc.
W. Grease Box ----------1pc. X. Grease Tray -------- 1pc.
Y. Diagonal Bar Barrier -----1pc.
Z. Warming Rack ----------1pc.
ZA. Flame Tamers-------4pcs
ZB. Cooking Grids----------2pcs.
Before beginning assembly, make sure all parts are present. Compare parts with package contents list
and diagram above. If any part is missing or damaged, do not attempt to assemble the product. Contact
customer service for replacement parts.
· Estimated Assembly Time: 50 minutes
· Tools Required for Assembly:
Phillips Screwdriver (not included) and Wrench (not included)
· Note: The right and left sides of the grill are designated as if you are facing the front of the grill.
