Grillo AWD 27 - Technical Specifications 10 Awd 27

Climber 10/ Translation of the original instructions
CUTTING SYSTEM: 1 single blade fitted with swing tips and double cutting edge.
CUTTING WIDTH: 930 mm.
PERIPHERAL BLADE SPEED: 83 m/sec.
CUTTING HEIGHT: from 35 mm to 135 mm with continuous adjustment.
HOURLY CUTTING CAPACITY: 7200 m
2
/h.
INTERNAL STEERING RADIUS: 70 cm.
STANDARD FEATURE: tow bar, front headlight.
WEIGHT: 345 kg
SIZE: Length 2,060 mm – Width 1,030 mm – Height 1,185 mm.
Distance between axles: 1,420 mm.
TECHNICAL SPECIFICATIONS 10 AWD 27
ENGINE: - BRIGGS & STRATTON 8270 Series, OHV, 724cc twin-cylinder petrol version equipped
with vertical shaft and Cyclonic air filter.
FUEL TANK: 13 litres.
STARTER: electric with 12V battery.
GEARBOX: 4-wheel-drive hydrostatic transmission.
DIFFERENTIAL LOCK: on the rear axle, with pedal engagement.
CLUTCH: electromagnetic with P.T.O and blade brake.
SPEED: continuously variable from 0 to 9 km/h + reverse speed from 0 to 8 km/h.
TYRES: front 16x6.50-8 TRACTOR puncture proof treated; rear 20×10.00-8 TRACTOR.
BRAKES: parking brake on the rear wheels with lever engagement.
SEAT: sprung and adjustable, equipped with roll-bar.
CUTTING DECK: rear/side discharge.
CUTTING SYSTEM: 1 single blade fitted with swing tips and double cutting edge.
CUTTING WIDTH: 980 mm.
PERIPHERAL BLADE SPEED: 87 m/sec.
CUTTING HEIGHT: from 35 mm to 135 mm with continuous adjustment.
HOURLY CUTTING CAPACITY: 7500 m
2
/h.
INTERNAL STEERING RADIUS: 70 cm.
STANDARD FEATURE: tow bar, double front headlight.
WEIGHT: 355 kg
SIZE: Length 2,060 mm – Width 1,080 mm – Height 1,185 mm.
Distance between axles: 1420 mm
9
