STEERING SYSTEM: with levers.
CLUTCH: for electromagnetic PTO, with magnetic blade brake.
SPEED: 0-12 km/h: continuous variation.
WHEELS: front 20×10-8; rear 15×6-6.
BRAKE: mechanical parking brake.
ELECTRICAL DECK TILTING FOR INSPECTION AND MAINTENANCE.
SEAT: comfort adjustable and sprung seat with armrests.
STEERING LEVERS: adjustable in height and longitudinally.
STEERING RADIUS: zero.
ACCESSORIES: 1320 cutting deck, 1250 mm cutting width, weight 125 kg (the cutting
device includes frame and operator board).
MULCHING/REAR DISCHARGE FROM DRIVER’S SEAT.
HOURLY MOWING CAPACITY: 15.000 m2/h.
SIZE (with cutting deck): Length: 2580 mm, Width: 1320 mm, Height: 1100 mm.
CLEAR SPAN FROM THE GROUND: 95 mm.
DISTANCE BETWEEN AXLES: 1022 mm.
WEIGHT (without cutting deck): 340 kg - WEIGHT (with cutting deck): 465 kg.
PUTTING THE MACHINE INTO SERVICE
- Make sure the machine is complete and that it has not suffered any damage during transit.
- Check the oil level of: the engine (fig. 4, ref.A), the hydrostatic transmission (fig. 5, ref.A)
and the stabilizing device (fig. 6, ref. A)
- Check the tyre pressure: Front wheels 20×10.00-8 (1,2 bar in exercise) - Rear wheel
15×6.00-6 (1 bar in exercise)
- Check the battery voltage, it must not be less than 12.5 Volts; recharge if necessary.
BATTERY
Caution! The gases released by the battery are explosive, so keep it away from naked
flames or sparks.
Check the level of the liquid at regular intervals and keep the terminals greased with
vaseline.
Important:
- Do not invert the battery poles.
- Do not run the lawnmower without the battery, as it is equipped with a charge
regulator.
- Be careful not to cause short circuits.
RUNNING IN – CAUTION!
Change the engine oil and filter after the first 8 hours of work. Check for oil leaks or loose
screws, especially those that fix the blades and the wheels. Adjust the PTO belts tension
with the nut on the corresponding spring: the spring length has to be adjusted at 85 mm (fig.
19, ref.A).
Before turning on the engine always check that:
