Fig. 1
1. Starting key
2. Hour meter
3. Oil warning light
4. Front brake pedal (for emergency only)
5. Differential lock pedal
6. PTO switch
7. Parking brake
1. Chiave avviamento
2. Contaore
3. Spia olio
4. Pedale freno anteriore (solo emergenza)
5. Pedale bloccaggio differenziale
6. Interruttore PTO
7. Frano di parcheggio
1. Clé de démarrage
2. Compteur horaire
3. Témoin huile moteur
4. Pédale frein avant (en cas d'urgence seulement)
5. Pédale du blocage différentiel
6. Interrupteur prise de force
7. Frain de parking
1. Zündschlüssel
2. Stundenzähler
3. Ölkontrollleuchte
4. Pedal der Vorderbremse (nur im Notfall)
5. Pedal der Differentialsperre
6. Zapfwellenschalter
7. Feststellbremse
1. Llave de arranque
2. Contador horario
3. Testigo aceite
4. Pedal freno delantero (sólo de emergencia)
5. Pedal bloqueo del diferencial
6. Interruptor PTO
7. Freno de aparcamiento
2
6
5
3
1
4
7
62
