31
ENGLISH
2 APPLIANCE DESCRIPTION
2.1 Appliance use
Your purchased machine for professional use is suitable for
producing coee, hot water and steam.
2.2 Main components
The main components of the appliance are listed below:
1) Removable warming plate for saucers and cups
2) Cup warmer (optional)
3) Control panel (see section. 2.4)
4) Hot water wand
5) Brew group
6) Drip tray with grill
7) Steam wand
8) Feed cable
9) Main selector switch
10) Steam wand rubber guard
11) Boiler resistance ON warning light
12) Dispensing gauge (water network + pump pressure)
13) Boiler pressure gauge
14) Loading water into the boiler warning light
15) Steam dispensing wheel
16) Cup warmer ON key (where foreseen)
4
15
10
8 12
13 14
6
7
1
9
7
10
11
15
16
2 3 5
