Manual EDM 180
Revision 1.0 29.03.2010 Page 46/61
7 Switching possibilities of the GRIMM 190
7.1 With a terminal program
Previous to switching the device it has to be within service mode 0. Therefore a terminal program is
necessary.
Following versions are possible:
Version 7.80
PM10, PM 2.5, PM1 in storage, LCD and via the RS.232 interface.
Version 12.30
31 channels particle counts/ size distribution in storage, LCD and via the RS.232 interface
Switching into service mode 0 following steps are to be done:
- Send the character | (possible by Alt Gr and the key < >, or by Alt 124 on the NumBlock. I.e. the
ASCII code 124 is decimal).
- Press „TAB“
- Press „v“ for control
- Next to the firmware also the date of the firmware has to be visible
Example Grimm 190:
without service mode
V
Version : 7.80 E
with service mode
|
V
Version : 7.80 E DM180G 23.1.2008 87C552:011 DM180GL 23.01.2008
or
|
V
Version : 12.30 E DM180G 23.1.2008 87C552:011 DM180GL 23.01.2008
With Ctrl and v and then { (brace open, ASCII 123) the device switches into version 7.80
With Ctrl and v and then } (brace closed, ASCII 125) the device switches into version 12.30
IMPORTANT:
Read out the data storage card BEFORE you change the version, because the storage re-
initializes after converting.
