Installation, care and maintenance Minette
4
Product description
Applications
Minette is intended to be used for:
— pumping of water which may contain abrasive
particles.
The pumps are available in the following
versions: 1 - 3 phase.
Liquid temperature: standard version, max.
40°C (104°F).
Liquid density: max. 1100 kg/m
3
(9.2 lb per US
gal.).
The pumped liquid may contain particles up to
a size which corresponds to the openings in the
strainer. See drawing.
The pH of the pumped liquid: 5 – 8.
Depth of immersion: max. 20 m (65 ft).
For other applications contact your nearest
Grindex representative for information.
WARNING!
The pump may not be used
in an explosive or ammable
environment or for pumping
ammable liquids.
WARNING!
If the pump run dry or snore,
the pump surface and the sur-
rounding liquid may be hot.
Bear in mind the risk of burn
injuries.
WARNING!
The machine is not to be
installed in locations classied
as hazardous in accordance
with the national electric code,
ANSI/NFPA 70-1990
Voltage
V
Rated current
A
Starting current
A
220 D 8.1 44
230 D 8.1 47
380 Y 4.7 25
400 Y 4.7 27
415 Y 4.7 28
500 Y 3.7 21
550 Y 3.9 24
3~ 50 Hz, 2800 r/min
Rated output: 2.2 kW (3.0 hp)
Max cons.: 2,7 kW (3,6 hp)
Voltage
V
Rated current
A
Starting current
A
220 D 9.6 65
230 Y// 9.5 65
380 Y 5.6 37
460
Yser
4.7 32
480
Yser
4.9 34
575 Y 3.6 23
600 Y 3.6 24
3~ 60 Hz, 3410 r/min
Rated output: 2.6 kW (3.5 hp)
Max coons.: 3,1 kW (4,2 hp)
Motor data
Motor type: Squirrel-cage 1- or 3-phase in-
duction motor for 50 Hz and 60 Hz markets.
Voltage
V
Rated current
A
Starting current
A
220 8.7 31
230 8.4 32
240 8.3 34
1~ 50 Hz, 2830 r/min
Rated output: 1.5 kW (2.0 hp)
Max cons.: 1,9 kW (2,5 hp)
Voltage
V
Rated current
A
Starting current
A
220 10.0 35
230 9.9 37
240 9.8 39
1~ 60 Hz, 3405 r/min
Rated output: 1.8 kW (2.4 hp)
Max cons.:2,2 kW (3,0 hp)
