Grindex MINEX - Product Description; Applications; Motor Data

Installation, care and maintenance Minex
4
Product description
Applications
Minex is intended to be used for:
— pumping of water which may contain abrasive
particles.
The pumps are available in the following
versions: 1 - 3 phase.
Liquid temperature: standard version, max.
40°C (104°F).
Liquid density: max. 1100 kg/m
3
(9.2 lb per US
gal.).
The pumped liquid may contain particles up to
a size which corresponds to the openings in the
strainer. See drawing.
The pH of the pumped liquid: 5 – 8.
Depth of immersion: max. 20 m (65 ft).
For other applications contact your nearest
Grindex representative for information.
WARNING!
The pump may not be used
in an explosive or ammable
environment or for pumping
ammable liquids.
WARNING!
If the pump run dry or snore,
the pump surface and the sur-
rounding liquid may be hot.
Bear in mind the risk of burn
injuries.
WARNING!
The machine is not to be
installed in locations classied
as hazardous in accordance
with the national electric code,
ANSI/NFPA 70-1990
Vol-
tage
V
Rated
cur-
rent
A
Star-
ting
cur-
rent A
220 D 4.8 20
230 D 4.7 21
380 Y 2.8 12
400 Y 2.7 12
415 Y 2.7 13
500 Y 2.1 9
550 Y 2.1 10
3~ 50 Hz, 2740 r/min
Rated output: 1.2 kW (1.6 hp)
Max cons. 1.6 kW (2.1 hp)
Vol-
tage
V
Rated
cur-
rent
A
Star-
ting
cur-
rent A
220 D 5.4 29
230 Y// 5.2 27
380 Y 3.1 17
460
Yser
2.6 14
480
Yser
2.6 14
575 Y 1.8 9.9
600 Y 2.0 10
3~ 60 Hz, 3365 r/min
Rated output: 1.4 kW (1.9 hp)
Max cons. 1.8 kW (2.4 hp)
Motor data
Motor type: Squirrel-cage 1- or 3-phase in-
duction motor for 50 Hz and 60 Hz markets.
Vol-
tage
V
Rated
cur-
rent
A
Star-
ting
cur-
rent A
220 7.4 31
230 7.2 32
240 7.2 34
1~ 50 Hz, 2870 r/min
Rated output: 1.3 kW (1.8 hp)
Max cons. 1.6 kW (2.1 hp)
Vol-
tage
V
Rated
cur-
rent A
Star-
ting
cur-
rent A
115 12 49
220 6 23
230 5.8 24
240 5.7 26
1~ 60 Hz, 3410 r/min
Rated output: 1.0 kW (1.3 hp)
Max cons. 1.3 kW (1.8 hp)
Vol-
tage
V
Rated
cur-
rent
A
Star-
ting
cur-
rent A
115 15 74
1~ 60 Hz, 3460 r/min
Rated output: 1.3 kW (1.8 hp)
Max cons. 1.6 kW (2.1 hp)
Vol-
tage
V
Rated
cur-
rent A
Star-
ting
cur-
rent A
220 5.3 19
230 5.1 20
240 5.1 21
1~ 50 Hz, 2785 r/min
Rated output: 0.85kW (1.15 hp)
Max cons. 1.1 kW (1.5 hp)
Vol-
tage
V
Rated
cur-
rent
A
Star-
ting
cur-
rent A
220 8.4 35
230 8.2 37
240 8.2 39
1~ 60 Hz, 3460 r/min
Rated output: 1.3 kW (1.8 hp)
Max cons. 1.6 kW (2.1 hp)
