-8-
G0529 Oscillating Spindle & Disc Sander
1. Sanding Spindle
2. Cast Iron Spindle Sanding Table
3. Power Switch
4. Motor
5. Sanding Disc
6. Cast Iron Disc Sanding Table
7. Miter Gauge
8. Dust Ports (Spindle Port Not Shown)
9. Cabinet
10. Graduated Scales
SECTION 4: MACHINE FEATURES
Figure 2. Machine Features.
An important part of safety is knowing your machine and its components. Take the time to familiarize
yourself with the features of your new G0529 Oscillating Spindle & 12" Disc Sander. They will be fre-
quently mentioned throughout the instructions in this manual.
1
10
9
8
7
6
5
4
3
2
