REF PART # DESCRIPTION REF PART # DESCRIPTION
5 P0605X137 STRAIN RELIEF 95 P0605X1095 STRAIN RELIEF PGA13.5-11B
7 PN02M HEX NUT M10-1.5 96 PB32M HEX BOLT M10-1.5 X 25
8 PW04M FLAT WASHER 10MM 97 P0651097 FENCE RESTING BRACKET
9 PLW06M LOCK WASHER 10MM 98 P0605X1098 STRAIN RELIEF
16 PFB15M FLANGE BOLT M8-1.25 X 12 99 PB20M HEX BOLT M8-1.25 X 35
27 PLW04M LOCK WASHER 8MM 100 P0605X1100 CHAIN
38 PK14M KEY 5 X 5 X 18 101 P0605X116 EXTENSION WING (L)
39 PB14M HEX BOLT M10-1.5 X 35 102 PFH54M FLAT HD SCR M5-.8 X 20
42 PSB31M CAP SCREW M8-1.25 X 25 103 P0605X1103 TABLE INSERT
43 P0605X1043 WOODRUFF KEY 22 X 5 104 PSS04M SET SCREW M6-1 X 12
47 P0605X1047 HANDWHEEL 105 P0605X1105 PLATE (L)
48 P0605X014 HANDWHEEL LOCK KNOB 106 P0605X1106 PLATE (R)
49 PSS17 SET SCREW 5/16-18 X 5/16 107 P0605X1107 TAPE (L)
52 P0605X1052 FLAT WASHER 19MM 108 P0605X1108 TAPE (R)
55 PN03M HEX NUT M8-1.25 109 P0605X1109 RIVING KNIFE
73 P0605X1073 ALIGNMENT PIN 110 P0605X035 TABLE
74 P0605X073 MOTOR COVER 111 PHTEK39M TAP SCREW M4 X 12
75 P0605X1075 RUBBER BUMPER 112 P0605X1112 CABINET
76 P0605X1076 LOCK KNOB M6-1 X 17 113 P0605X1113 WORM GEAR
79 P0605X1079 RIGHT COVER 114 P0605X1114 BLADE TILT SHAFT BRACKET
82 PSB26M CAP SCREW M6-1 X 12 115 P0605X1115 BLADE TILT SHAFT
83 P0605X1083 COVER 116 P0651083-6 SENSOR PLATE
84 PS05M PHLP HD SCR M5-.8 X 8 117 PSS16M SET SCREW M8-1.25 X 10
88 P0651083 DIGITAL SENSOR ASSEMBLY 118 P0605X1118 SPECIAL RING
88-1 PS05M PHLP HD SCR M5-.8 X 8 119 P0651112 L-PLATE
88-2 P0651083-2 DIGITAL READOUT COVER 120 PW02M FLAT WASHER 5MM
88-3 PS79M PHLP HD SCR M3-.5 X 8 121 PHTEK30M TAP SCREW M3 X 6
88-4 PW07M FLAT WASHER 3MM 122 PRP27M ROLL PIN 5 X 28
88-5 P0651083-5 CIRCUIT BOARD 123 P0651106 MITER GAUGE MOUNTING BRACKET
88-6 P0651083-6 SENSOR PLATE 124 P0605X1124 HANDWHEEL HANDLE
88-7 P0651083-7 DATA CORD 24 AWG X 450 136 P0651107 WRENCH MOUNTING BRACKET
88-8 P0651083-8 DIGITAL READOUT CORD 18 AWG X 2C 137 P0651087 DUST COVER
89 PS79M PHLP HD SCR M3-.5 X 8 138 P0651108 ARBOR WRENCH
90 PN06M HEX NUT M5-.8 139 PFH06M FLAT HD SCR M6-1 X 20
91 P0605X079 PLATE 152 P0696X152 EXTENSION WING
92 PS17M PHLP HD SCR M4-.7 X 6 152-1 PLW06M LOCK WASHER 10MM
93 PW05M FLAT WASHER 4MM 152-2 PB14M HEX BOLT M10-1.5 X 35
94 PSS42M SET SCREW M8-1.25 X 50
Cabinet Parts List
