Grizzly G0623X User Manual

96 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

COPYRIGHT © NOVEMBER, 2007. BY GRIZZLY INDUSTRIAL, INC. REVISED FEBRUARY, 2013 (TR)

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

#TR9147 PRINTED IN TAIWAN

G0623X ONLY

MODEL G0623X/G0623X3

10" SLIDING TABLE SAW

OWNER'S MANUAL

(For models manufactured since 05/12)

Table of Contents

Other manuals for Grizzly G0623X

Machine Data Sheet3 pages

Questions and Answers:

A
Amy FrankAug 27, 2025
What to do if workpiece has burned edges, binds, or kicks back on my Grizzly G0623X?
- M
  Maria GriffinAug 27, 2025
  If the workpiece has burned edges, binds, or kicks back when using your Grizzly Saw, consider the following: * The sliding table might not be parallel to the blade. Adjust the sliding table to be parallel with the blade. * The riving knife might not be aligned with the blade. Adjust the riving knife to align it with the main blade. * The blade might be warped. Replace the blade.
A
Andrew BrownAug 27, 2025
Why are cuts not square on my Grizzly G0623X Saw?
- A
  Amy RodgersAug 27, 2025
  If the cuts from your Grizzly Saw are not square, it could be due to: * The sliding table not being parallel to the blade. Adjust the sliding table. * The rip fence not being parallel to the blade. Adjust the rip fence to be parallel to the blade. * The crosscut fence not being perpendicular to the blade. Adjust the crosscut fence to be perpendicular to the blade.
A
Ariel DiazAug 28, 2025
What to do if my Grizzly Saw handwheels for blade adjustments will not turn or are difficult to turn?
- J
  Joseph MerrittAug 28, 2025
  If the handwheels for blade adjustments on your Grizzly Saw are difficult to turn or won't turn at all, check these: 1. Shipping braces may still be attached. Remove them. 2. The lock knob may be tight. Release it. 3. The gears may be caked with dust. Clean out the dust and grease the gears.
T
Tammy BakerAug 30, 2025
What to do if workpiece has chip out on the bottom edge when using my Grizzly G0623X Saw?
- T
  Tracy HopkinsAug 30, 2025
  If your workpiece has chip out on the bottom edge when using the Grizzly Saw, consider these solutions: * The scoring blade height may be incorrect. Adjust the height of the scoring blade. * The scoring blade might not be aligned with the main blade. Align the scoring blade. * The scoring blade kerf may not match the main blade. Adjust the scoring blade kerf.
J
Jeremiah McdonaldAug 31, 2025
What to do if Fence hits table top when sliding across table on my Grizzly Saw?
- J
  julie39Aug 31, 2025
  If the fence hits the tabletop when sliding across the table on your Grizzly Saw, it could be because: 1. The front rail is too low. Raise the front rail. 2. The rip fence roller is too low. Adjust the rip fence roller.
H
hwyattSep 3, 2025
What to do if my Grizzly G0623X Saw workpiece has burned edges, binds, or kicks back?
- P
  parker51Sep 3, 2025
  If your Grizzly Saw workpiece has burned edges, binds, or kicks back, it could be due to a few reasons. The sliding table might not be parallel to the blade, the riving knife may not be aligned, or the blade itself could be warped. To resolve this, make sure the sliding table is parallel to the blade. Shim the riving knife to align it properly with the main blade. If the blade is warped, replace it.
D
David GreenSep 4, 2025
How to fix a Grizzly Saw sliding table that does not cut square?
- W
  William MedinaSep 4, 2025
  If your Grizzly Saw's sliding table saw does not cut square, there are a few potential causes. The sliding table might not be parallel to the blade, the rip fence could be misaligned, or the crosscut fence may not be perpendicular to the blade. To fix this, you should adjust the sliding table to ensure it is parallel to the blade. Also, adjust the rip fence so that it is parallel to the blade. Finally, adjust the crosscut fence so that it is perpendicular to the blade.
J
Jessica AcostaSep 5, 2025
Why are the handwheels for blade adjustments on my Grizzly Saw difficult to turn?
