Grizzly G0623X User Manual

-4-
Model G0623X/G0623X3 (Mfg. Since 5/12)
Model Number G0623X G0623X3
Product Dimensions
Weight
533 lbs
Width (side-to-side)/Depth (front-
to-back)/Height
76 x 124-3/4 x 46 in.
Foot Print (Width/Depth) 25-1/5 x 28 in. 60 x 28 in.
Shipping Dimensions
Carton 1
Type Wood Crate
Content Machine
Weight 570 lbs. 556 lbs.
Width (side-to-side)/Depth (front-
to-back)/Height
46 x 42 x 44 in.
Carton 2
Type Cardboard
Content Sliding Table & Fence
Weight 118 lbs.
Width (side-to-side)/Depth (front-
to-back)/Height
67 x 18-1/2 x 10 in.
Electrical
Power Requirement 230V, Single-Phase, 60 Hz 220V or 440V, 3-Phase, 60 Hz
Prewired Voltage 230V 220V
Full-Load Current Rating 19A 20A @ 220V, 10A at 440V
Minimum Circuit Size 30A 30A @ 220V, 15A @440V
Switch Magnetic with Themal Overload Protection
Recommended Power Cord “S”-Type, 3-Wire, 10 AWG, 300 VAC
“S”-Type, 4-Wire, 10 AWG, 300 VAC for
220V, Permanent Connection for 440V
Plug Included No
Recommended Plug/Outlet Type L6-30
L15-30 for 220V; Permanent Connection
for 440V
Voltage Conversion Kit Not Applicable Requires Part# G440VG0623X3
Recommended Phase Converter Not ApplicableT G5845
Main Motor
Type TEFC Capacitor Start Induction
Horsepower 5 HP 7.5 HP
Voltage 230V 220V/440V
Prewired Not Applicable 220V
Phase Single 3-Phase
Amps 19A 20A @ 220V, 10A @ 440V
Speed 3450 RPM
Cycle 60 Hz
Power Transfer V-Belt Drive
Bearings Sealed and Lubricated
model G0623X/G0623X3
10" SlIdING TABle SAW
