Grizzly G0623X User Manual

Model G0623X/G0623X3 (Mfg. Since 5/12)
-81-
Sliding Table Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
301 P0623X0301 SLIDING TABLE SET 688 X 316 326 PN09M HEX NUT M12-1.75
302 P0623X0302 T-SCREW M12-1.75 X 35 327 P0623X0327 ADJUST FOOT
303 PW06M FLAT WASHER 12MM 328 P0623X0328 SWITCH MOUNTING BRACKET
304 PLW05M LOCK WASHER 12MM 330 PS56M PHLP HD SCR M4-.7 X 16
305 PN09M HEX NUT M12-1.75 331 PCAP33M CAP SCREW M5-.8 X 12
306 PLW03M LOCK WASHER 6MM 332 P0623X0332 LOCATE PLATE
307 PN01M HEX NUT M6-1 333 PN06M HEX NUT M5-.8
308 PN13M HEX NUT M16-2 334 PW02M FLAT WASHER 5MM
309 PBHS11M BUTTON HD CAP SCR M6-1 X 10 335 PLN05M LOCK NUT M10-1.5
310 PBHS11M BUTTON HD CAP SCR M6-1 X 10 336 PWF10M FENDER WASHER 10MM
311 P0623X0311 LOCATE PLATE 337 PFN02M FLANGE NUT M6-1
312 P0623X0312 LOCATE PLATE 338 PCAP33M CAP SCREW M5-.8 X 12
313 P0623X0313 HANDLE 339 PW02M FLAT WASHER 5MM
314 P0623X0314 LOCATE PLATE 340 PN06M HEX NUT M5-.8
315 PCAP01M CAP SCREW M6-1 X 16 341 PW03M FLAT WASHER 6MM
316 P0623X0316 PIN LOCK 342 PLW03M LOCK WASHER 6MM
317 PCAP115M BUTTON HD CAP SCR M6-1 X 16 343 PN01M HEX NUT M6-1
318 PBHS11M BUTTON HD CAP SCR M6-1 X 10 344 P0623X0344 FLEXIBLE CONDUIT
319 P0623X0319 SLIDING TABLE END PLATE 345 P0623X0345 LOCATE PLATE
320 P0623X0320 SLIDING TABLE END PLATE 347 P0623X0347 MOTOR CORD 12G 4W
321 P0623X0321 LOCATE BLOCK 348 P0623X0348 PWR BOX CORD 12G 3W (G0623X)
322 P0623X0322 LOCATE PLATE 348 P0623X30348 PWR BOX CORD 12G 4W (G0623X3)
323 PLW04M LOCK WASHER 8MM 349 P0623X0349 LIMIT SWITCH CORD 18G 2W
324 PCAP14M CAP SCREW M8-1.25 X 20 350 P0623X0350 E-STOP CORD 18G 2W
325 P0623X0325 SUPPORT LEG
REF PART # DESCRIPTION
329V2 P0623X0329V2 MAG SWITCH NHD MS 1-18D V2.09.10
329V2-1 P0623X0329V2-1 SWITCH BOX NHD
329V2-2 P0623X0329V2-2 CONTACTOR NHD C-18D 230V
329V2-3 P0623X0329V2-3 OL RELAY NHD NTH-21 17-21A
329V2-4 P0623X0329V2-4 SWITCH BOX SCREW NHD
REF PART # DESCRIPTION REF PART # DESCRIPTION
329A P0623X30329A MAG SWITCH MP-18 7.5HP 220V 3PH 346A P0623X30346A MAG SWITCH MP-18 7.5HP 440V 3PH
329-1A P0623X30329-1A SWITCH BOX 346-1A P0623X30346-1A SWITCH BOX
329-2A P0623X30329-2A CONTACTOR SDE MA-18 220V 346-2A P0623X30346-2A CONTACTOR SDE MA-18 440V
329-3A P0623X30329-3A RELAY SDE RA-30 18-26 20A 346-3A P0623X30346-3A RELAY SDE RA-20 8-12 10A
G0623X 5HP, 230V, 1-PH SWITCH
G0623X3 7.5HP, 220V, 3-PH SWITCH
G0623X3 7.5HP, 440V, 3-PH SWITCH
