REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0710P001 WALL MOUNTING BRACKET 13 G8988 PADDLE SWITCH W/KEY
2 P0710P002 MOTOR BRACKET 14 PWRCRD110L POWER CORD 16AWG 3C 5-15
3 PS09M PHLP HD SCR M5-.8 X 10 15 P1163021 COLLECTION BAG 13-1/2" X 24"
4 P0710P004 INLET COVER 11" 16 PK23M KEY 5 X 5 X 25
5 PCAP121M CAP SCREW M6-1 X 20 LH 17 P1163023 QUICK RELEASE BAG CLAMP
6 P0710P006 IMPELLER WASHER 6MM 18 P1163027 HANDLE COVER
7 P1163011V2 IMPELLER 10" 19 P1163028 HANDLE END CAP
8 PSS02 SET SCREW 5/16-18 X 3/8 20 P0710020 INLET COVER GASKET
9 P0710P009 COLLECTOR BODY W/HANDLE 21 P0710021 FOAM STRIP 4 X 20 X 430MM
10 P1032019 MOTOR SHAFT SPACER 31 PLABEL-12B READ MANUAL LABEL
11 P0710P011 MOTOR 1HP 110/220V 1PH 32 PLABEL-57B EYE/LUNG INJURY LABEL
11-1 P0710P011-1 FAN COVER 33 P0710P033 MACHINE ID LABEL
11-2 P1163016V2-2 MOTOR FAN V2.06.08 34 P0710034 OUTLET DIRECTION LABEL
11-3 P0710P011-3 CAPACITOR COVER 35 PLABEL-59C AMPUTATION HAZARD LABEL
11-4 P1163016V2-4V2 S CAPACITOR 200M 125V V2.09.11 36 PPAINT-24 POLAR BEAR WHITE PAINT
11-5 P0710P011-5 JUNCTION BOX 37 PLABEL-14 ELECTRICITY LABEL
11-6 P1163016V2-6 R CAPACITOR 30M 250V V2.09.11 38 PLABEL-81 POLAR BEAR LOGO 1 X 3-3/4
12 PFB03 FLANGE BOLT 1/4-20 X 1/2
