Model G4002/G4003 (Mfd. Since 3/14)

REF PART # DESCRIPTION REF PART # DESCRIPTION

401V2 P4002401V2 HANDLE V2.08.12 437 P4002437 SAFETY SHIFTER

402V2 P4002402V2 HANDWHEEL V2.08.12 438 P4002438 CAP SCREW M8-1.25 X 6

403V2 P4002403V2 GRADUATED DIAL V2.08.12 439 P4002439 COMPRESSION SPRING 1 X 4.5 X 6

404V2 P4002404V2 SET SCREW M6-1 X 8 440 P4002440 STEEL BALL 6MM

405 P4002405 CAP SCREW M6-1 X 20 441 P4002441 BOSS

406 P4002406 BRACKET 442 P4002442 ROLL PIN 6 X 40

407V2 P4002407V2 GEAR SHAFT V2.08.12 443 P4002443 DOG

408 P4002408 BUSHING 444 P4002444 CAP SCREW M8-1.25 X 30

409 P4002409 ROLL PIN 5 X 30 445 P4002445 LEVER

410 P4002410 GEAR 50T 447 P4002447 SHAFT

411 P4002411 EXT RETAINING RING 19MM 448 P4002448 CAP SCREW M6-1 X 65

412 P4002412 GEAR SHAFT 449 P4002449 CAP SCREW M6-1 X 15

413 P4002413 GEAR 46T 450 P4002450 GEAR 16T

414 P4002414 GEAR 51T 451 P4002451 CAP SCREW M6-1 X 60

415 P4002415 ROLL PIN 5 X 30 451-2 P4002451-2 SPACER

417 P4002417 SHAFT 452 P4002452 HOUSING

418 P4002418 BUSHING 453 P4002453 THREAD DIAL

419-2 P4002419-2 GEAR W/BUSHING AND SPACER 454 P4002454 HEX NUT M6-1

420 P4002420 SHAFT 455 P4002455 HEX BOLT M6-1 X 16

421 P4002421 WORM 456 P4002456 HALF NUT 2 PC

422 P4002422 KEY 5 X 5 X 45 457 P4002457 HALF NUT HOUSING 2 PC

423 P4002423 ROLL PIN 5 X 24 458 P4002458 CAP SCREW M6-1 X 25

424 P4002424 GEAR 14T 459 P4002459 GIB

425 P4002425 BUSHING 461 P4002461 SHAFT

426 P4002426 GEAR SHAFT B5 X 36 463 P4002463 GEAR 25T

427 P4002427 LEVER 464 P4002464 SET SCREW M6-1 X 6

428 P4002428 ROLL PIN 5 X 24 465 P4002465 APRON CASE

429 P4002429 STEEL BALL 6MM 466 P4002466 WORM BRACKET

430 P4002430 COMPRESSION SPRING 1 X 4.5 X 6 467 P4002467 LIMIT BLOCK

431 P4002431 SET SCREW M6-1 X 8 468 P4002468 OIL PLUG M10-1.5 X 20

432 P4002432 CAP SCREW M6-1 X 45 469 P4002469 SET SCREW M6-1 X 20

433 P4002433 BOSS 470 P4002470 SPANNER CAP SCREW

434 P4002434 WASHER 471 P4002471 KEY 5 X 5 X 20

435 P4002435 CAP SCREW M6-1 X 40 1104 P40021104 OIL WINDOW 12MM

436 P4002436 SHAFT

Apron Parts List
