Groen DEE/4-20 Series User Manual

13 OM-DEES(T)-40(C,A,C2T™) Domestic
Parts List
To order parts, contact your Authorized Service Agent. Supply the model designation, serial number, part description, part number,
quantity, and when applicable, voltage and phase.
KEY DESCRIPTION PART #
1 WATER FILL ASSY 097007
2 SAFETY VALVE 097005
3 CHECK VALVE 004187
4 PRESSURE GAUGE 084208
5 KBS AND TRUNNION, NO TDO 20
KBS AND TRUNNION, NO TDO 40
KBS AND TRUNNION, NO TDO 60
KBS AND TRUNNION, TDO-2 20
KBS AND TRUNNION, TDO-2 40
KBS AND TRUNNION, TDO-2 60
175117
175125
175154
175120
175128
175157
6 STAND AND HOUSING ASSY 20
STAND AND HOUSING ASSY 40, 60
175401
175419
7A KNOB, TEMP CONTROL, CLASSIC 175095
7B KNOB, TEMP CONTROL, ADVANCED & C2T 174829
8 LIGHT, RED 116383
9 LIGHT, AMBER 116384
10 POWER SWITCH 176921
11 ELECTRICAL MOUNT ASSY 175404
12 TILT SWITCH 002982
13 CONTACTOR 148102
14 TRANSFORMER, 208/240V/24V 40VA
TRANSFORMER, 480V/24V 40VA
137441
137694
15 GROUND TERMINAL 129714
16 FUSE HOLDER 077854
17 FUSE, 3 AMP 077853
18 WATER LEVEL BOARD 122192
19 PRESSURE SWITCH 096963
20 CONTROL - CLASSIC
CONTROL - ADVANCED
CONTROL - C2T
174843
174837
176895
21 WATER LEVEL PROBE 070178
22 ELEMENT, 208V 3.6KW
ELEMENT, 480V 4 KW
ELEMENT, 208V 9.95KW
ELEMENT, 240V 8KW
ELEMENT, 480V 8KW
011094
011088
005977
005974
005980
23 FOOT, ADJUSTABLE BULLET
FOOT FLANGED
013275
096569
24 HANDLE, CRANK 013617
26 SHAFT, HANDWHEEL 013624
27 WELDMENT, FRAME, STAND 20
WELDMENT, FRAME, STAND 40 60
174805
174802
28 WELDMENT, CLADDING, STAND 20 174806
29 WELDMENT, PEDESTAL 20 175379
30 WELDMENT, CLADDING, PEDESTAL 20 175378
KEY DESCRIPTION PART #
31 GEAR BORE 013609
32 WORM GEAR 012026
33 BEARING 009765
34 BEARING HOUSING 009762
35 KEY 3/8" 001474
36 SET SCREW 012060
37 WATER LEVEL ASSEMBLY 065198
38 FITTINGS, SIGHT GLASS ASSEMBLY 002845
39 GUARD, GLASS ROD GAUGE 002981
40 TUBE, WATER LEVEL 008742
41 ELBOW, F 90 DEG 1/2 NPT X 1/2" TUBE 055634
42 BUSHING, REDUCING 1/4" X 1/8" NPT 074872
43 ELECTRODE, WATER LEVEL 002170
44 RTD, LARGE KETTLES 175101
45 FITTING, COMPRESSION 175099
X COVER, BOTTOM 20 003333
X COVER, BOTTOM 40 60 003334
X PANEL, SIDE PEDESTAL 175383
X COVER, LOWER TRUNNION SUPPORT ARM 116308
X COVER, UPPER TRUNNION SUPPORT ARM 116305
X OVERLAY, CLASSIC CONTROL 175303
X OVERLAY, ADVANCED CONTROL 175304
X DECAL, OPERATING INSTRUCTIONS, CLASSIC CTRL 175298
X DECAL, OPERATING INSTRUCTIONS, ADVANCED CTRL 175610
X BEAD, FERRITE 175836
X HARNESS, WIRE 149947
X HARNESS, HIGH VOLTAGE 149942
X HARNESS, CONTROL 175405
X OVERLAY, C2T CONTROL 176891
X CORE PROBE, DEE-20 & 40, C2T 176651
X CORE PROBE, DEE-60, C2T 176652
X BRACKET, CORE PROBE, DEE-20, C2T 176654
X BRACKET, CORE PROBE, DEE-40, C2T 176655
X BRACKET, CORE PROBE, DEE-60, C2T 176656
X BRACKET ASSEMBLY, CORE PROBE STORAGE 177091
X SOCKET, PANEL MOUNT ASSY, CORE PROBE, C2T 176925
X CAP, SOCKET, PANEL MOUNT, CORE PROBE, C2T 176927
X WIRE HARNESS, CONTROL, CORE PROBE, C2T 176920
X WIRE HARNESS, CONTROL, DEE, C2T 177261
x- Item not depicted/called out in drawing
