8
Open/Close Handle
Operation
WARNING
ANY POTENTIAL USER OF THE EQUIPMENT MUST BE TRAINED IN SAFE AND CORRECT OPERATING
PROCEDURES.
A. Controls
Operator controls are on the front right of the unit.
The VRC-3E and VRC-6E control panels have the
following touch pads and indicator lights:
! The ON/OFF touch pad gets the
Vortex™ ready for use, or shuts it off.
! The HOLD indicator light shows that the
cavity is at holding temperature.
! The TIMING indicator light stays on
when the timer is running.
! The ADD H20 indicator light is lit when
it’s time to add water.
! The open and closed position of the
drain valve allows the unit to be filled
with water or drained. This is also used
to manually reset the unit.
! The HI TEMP indicator light comes on
when the bottom of the water reservoir
becomes too hot.
The unit will automatically shut off, and
cannot be turned on again until the water
reservoir cools down.
! The HI TEMP light will remain
illuminated until the controls are turned
on and the unit temperature is low
enough to restart. Then reset the
manual reset latch as indicated on the
bottom label.
! When power has been interrupted to
the Vortex or the HI TEMP light has
come on, the RESET light will illuminate.
The drain handle will need to be
momentarily opened or closed to
extinguish light.
