Groeneveld AC3 - Page 10

AC3OperaonandMaintenance
Pump Refill Procedure
TheAC3Groeneveldmullinepumpsarefiedwithagreasenippleadaptorasstandard(see‘1’below)forfilling
withmosttypesofgreaseuptoandincludingNGLIGrade2.Usingthegreasenippleadaptorforgreasefillavoids
thepossibilityofairentrapmentandairpockets(cavitaon).
Bulkfilladaptorsarealsoavailableonspecialrequest.Thesecanbefiedasanalternavetothegreasenipplein
addiontothegreasenipple(see‘2’belowright).
IMPORTANT NOTES:
 Ensurethatthegreasenippleorbulkfilladaptoriscleanbeforerefilling.Placethedustcapbackonthe
greasenippleorbulkfilladaptorwhenfinished.

 DO NOT OVERFILL THE RESERVOIR. FillonlytotheMAXLevelLabel.

7
Operaon
AC3 System Output
(cc’s/grams per hour)
Timer Seng (Delay Cycle)
#0
1.8rpm
#1
0.9rpm
#2
3min
#3
7min
#4
11min
#5
15min
#6
19min
#7
24min
#8
30min
#9
36min
Red
0.53 0.3 0.15 0.07 0.05 0.04 0.03 0.024 0.019 0.016
Green
0.8 0.44 0.22 0.11 0.07 0.06 0.04 0.036 0.03 0.02
Yellow
1.33 0.74 0.36 0.18 0.12 0.09 0.07 0.06 0.05 0.04
Blue
2.12 1.18 0.58 0.3 0.2 0.15 0.12 0.1 0.08 0.06
Grey
3.19 1.77 0.87 0.44 0.3 0.22 0.18 0.14 0.12 0.1
Black
5.31 2.96 1.45 0.74 0.49 0.37 0.3 0.24 0.19 0.16
Injector
