Spare Parts
AC3OperaonandMaintenance 11
AC3xxx/x SPARES ORDERING METHOD
ITEM
NO.
PART NUMBER ‘F’ NUMBER DESCRIPTION QTY.
1
AC3/SP9
ACR/SP1
F800043
F801125
AC3 RESERVOIR ASSEMBLY
AC3 RESERVOIR ASSEMBLY W/ TOP FILL
1
1a 25153-965 F801191 AC3 RESERVOIR O-RING
2 83416-352 F800036 PADDLE AND WIPER ASSEMBLY 1
3 
AC3/SP5-1 F801177 12 PORT CAMSHAFT ASSEMBLY
1 
AC3/SP5-2 F801178 24 PORT CAMSHAFT ASSEMBLY
AC3/SP5-3 F801179 36 PORT CAMSHAFT ASSEMBLY
AC3/SP5-4 F801180 48 PORT CAMSHAFT ASSEMBLY
AC3/SP5-5 F801181 60 PORT CAMSHAFT ASSEMBLY
4 83416-317 F801183 ZERK GREASE NIPPLE ASSEMBLY 1
5 83416-607 F801184 QUICK FILL ADAPTOR AND DUST CAP FOR AC3 1
6 21885-810 F801185 SELF LOCKING NUT (M10) 1
7 21171-806 F801186 FLAT WASHER (M10) 1
8 38580-126 F801187 AC3 MOUNTING BRACKET 1
9 21831-227 F801188 M4x16 PAN HEAD SCREW 6
10 21181-722 F801189 M4 SHAKE-PROOF WASHER 6
11 25153-966 F801190 AC3 MANIFOLD TOP O-RING 1
12 
32478-221 F800081 12 PORT MANIFOLD
1 
32478-222 F800082 24 PORT MANIFOLD
32478-223 F800083 36 PORT MANIFOLD
32478-224 F800084 48 PORT MANIFOLD
32478-225 F800085 60 PORT MANIFOLD
13
78033-PL F800091 0.010cc PUMPING UNIT (RED)
AS REQUIRED
78034-PL F800092 0.015cc PUMPING UNIT (GREEN)
78035-PL F800093 0.025cc PUMPING UNIT (YELLOW)
78036-PL F800094 0.040cc PUMPING UNIT (BLUE)
78037-PL F800095 0.060cc PUMPING UNIT (GREY)
78038-PL F800096 0.10cc PUMPING UNIT (BLACK)
14 34237-402 F800108 BLANKING PLUG
15

AC3/SP10/12V F800044 AC3 12VDC MOTOR HOUSING AND PCB ASM.
1

AC3/SP10/24V F800045 AC3 24VDC MOTOR HOUSING AND PCB ASM.
15a
25153-890 F801192 AC3 MOTOR HOUSING O-RING
1
16
AC3/SP8-12VDC F800041 12VDC STEPPER MOTOR
1
AC3/SP8-24VDC F800042 24VDC STEPPER MOTOR
17
AC3/SP2-12VDC F800037 AC3 12VDC CIRCUIT BOARD
1
AC3/SP2-24VDC F800038 AC3 24VDC CIRCUIT BOARD
*
H2-62
H2-65M
F801146
F801147
FILL ADAPTER—FEMALE QUICK COUPLER
DUST COVER FOR FEMALE QUICK COUPLER
1
*
1348-663-30/M
1348-663-65/M
F801150
F801151
30-FOOT MALE WIRE HARNESS ASSEMBLY
65-FOOT MALE WIRE HARNESS ASSEMBLY
* MDC-2 F801148
MALE DELPHI CONNECTOR (12010973-B x1)
MALE TERMINAL PINS (12124582-L x2)
CONNECTOR PORT SEALS (12041351-B x2)
1
* FDC-2 F801149
FEMALE DELPHI CONNECTOR (12015792-B x1)
FEMALE TERMINAL PINS (12124580-L x2)
CONNECTOR PORT SEALS (12041351-B x2)
1
1
