AC3OperaonandMaintenance 13
Accessories
Accessories
Split Convolute
Part No. Descripon/Line Capacity
39694A250 1/4”SplitConvolute(1Tube)
39694A375 3/8”SplitConvolute(2‐4Tubes)
39694A500 1/2”SplitConvolute(5‐7Tubes)
39694A625 5/8”SplitConvolute(8‐12Tubes)
39694A750 3/4”SplitConvolute(13‐19Tubes)
39694A1000 1”SplitConvolute(20‐35Tubes)
39694A1250 1‐1/4”SplitConvolute(36‐44Tubes)
‘F’ No.
F801116
F801117
F801118
F801119
F801120
F801121
F801122
39694A1500 F801123 1‐1/2”SplitConvolute(45‐76)
Ø4mm Nylon Tube
Part No. Descripon
152823‐50 Ø4mmODPrimedw/EP‐0GradeGrease(15m/50)
152823‐164 Ø4mmODPrimedw/EP‐0GradeGrease(50m/164)
152057‐50 Ø4mmODUn‐Primed(15m/50)
152057‐164 Ø4mmODUn‐Primed(50m/164)
‘F’ No.
F801102
F801103
F801100
F801101
Numbered Sleeves
Part No. Descripon
39257‐A1 Forupto12pointsystem
39257‐A2 Forupto24pointsystem
39257‐A3 Forupto36pointsystem
39257‐A4 Forupto48pointsystem
39257‐A5 Forupto60pointsystem
‘F’ No.
F800109
F800110
F800111
F800112
F800113
Ø4mm Elbow Connectors—Push
Part No. ‘F’ No. Thread Size
PM90412 F800123 1/8”NPT
PM90484 F800124 1/4‐28UNF
PM90485 F800125 5/16‐24UNF
PM90487 F800126 1/8”BSPT
PM90489 F800127 M6x1
PM90490 F800128 M8x1
PM90491 F800129 M8x1.25
PM90492 F800130 M10x1
 
 
38497S1 F617321 1/8”NPTSwivel
38497S2 F617322 1/4‐28UNFSwivel
Ø4mm Straight Connectors—Push Lock
Part No. ‘F’ No. Thread Size
PM80412 F800114 1/8”NPT
PM80484 F800115 1/4‐28UNF
PM80485 F800116 5/16‐24UNF
PM80487 F800117 1/8”BSPT
PM80489 F800118 M6x1
PM80490 F800119 M8x1
PM80491 F800120 M8x1.25
PM80492 F800121 M10x1
LE505‐PCM F800102 4mmODUnion
38497Y2 F801194 4mmODY‐Conn.
 
LE80512‐PL F617320 1/8”NPT

*Photosoffingsmaybealooserepresentaon
oftheiractualappearance.

*Otherfingsavailableuponrequest.
