9. Troubleshooting
ATTENTION
Due to the low loop current, the insulation resistance of the
monitored wires (B1, B2 and B3) must be checked! The
insulation resistance must be = 20 MΩ/km (wire manu-
facturer specication), otherwise disconnections may be
undetected.
INFORMATION
The operational states of the EV-x01 can be visualized
with SIMON LINK using a USB300-cable (only during
mains operation).
For more information about the operational status see 4.3.5:
“Operational status indicators (OK, ALARM and FAULT)” on
page 10
INFORMATION
The EV-x01 indications are only visible with mains power
connected.
10. Frequently asked questions
QUESTION: Why does the yellow LED (common fault) lights, although all recognizable and known causes have been elimina-
ted?
ANSWERS:
● The maintenance counter is expired and must be set back, via SIMON LINK.
● Battery deep discharge: If the error-message can not be set back by pressing the RESET-button for more than 5
seconds the battery must be replaced.
QUESTION: Why do I not get a fault indication when the battery is not plugged in or the connection cables are disconnected?
(yellow LED)?
ANSWER: The battery assessment is carried out in cycles and can last up to maximum 8 minutes. In the event of a battery
fault, the yellow LED is set. A disconnected or defective battery will signal a fault immediately.
QUESTION: Why does the safe opening / closing not work during emergency power operation?
ANSWER: The initiated OPEN or CLOSE action of the function “secured closing” and “secured opening” of the smoke vents
is only completed with a change to emergency power operation. When the system is in emergency power operati-
on, the ventilator switch is disabled and the smoke-vents can only be operated by the SHEV-alarm opened.
QUESTION: Why does the yellow LED in EV-HE077 ash constantly during SHEV-triggering?
ANSWER: The ashing of the yellow LED during SHEV-alarm at the emergency button EV-HE077 is initiated by the switch
itself and can not be changed.
