ARK 23.0H-A1 IFpP/41/150/102/[(1P16S)9S]M/-10+50/90 1.Constant current 25A charging to 486V;
2.Constant current 10A charging to 495V;
3.Constant current 2A charging to 495V;
ARK 25.6H-A1 IFpP/41/150/102/[(1P16S)10S]M/-10+50/90 1.Constant current 25A charging to 540V;
2.Constant current 10A charging to 550V;
3.Constant current 2A charging to 550V;
7.3 HVC 60050-A1
No. Items Specification
1 Model HVC 60050-A1
2 Input/output voltage range 90~585V
3 Rated current 25A
5 Operating ambient temperature
-10~50℃
6 IP rating IP65
7 Warranty ≥10 years
8 communication method CAN2.0
9 Dimensions (W/D/H) W650*D260*H185 mm ±2mm
10 Weight 8.5±1kg
11 Certification CE-EMC
12 Environmental requirements RoHS
7.4 ARK 2.5H-A1
No. Items Specification
1 Battery pack Module ARK 2.5H-A1
2 Nominal Capacity/Energy 50Ah/2.56kWh
3 Rated Capacity/Energy 45Ah/2.3 kWh
4 Nominal Voltage 51.2V
5 Operating Voltage 47.2 - 56.8V
6 Rated current(25 )℃ 25A
8 Battery Type Cobalt Free Lithium Iron Phosphate (LFP)
9 Operating ambient temperature -10~50℃
10 Storage conditions
﹣30℃~50℃/7 days; -20℃~45℃/6 months; 95%RH
11 Cooling Natural cooling
12 Dimension (W/D/H) W650*D260*H185 mm ±2mm
13 Weight
27±1kg
14 Installation Wall-mounted installation/floor standing installation
15 Warranty 10 Years
16 Ingress protection IP65
17 Cell safety certification IEC62619/UL1642
18 safety certification IEC62619/CE/RCM/ CEC
19 Transportation test standard UN38.3
20 Environmental requirements RoHS
21 Battery designation IFpP/41/150/102/[1P16S]M/-10+50/90
