LED indication Control Mechanism
LED light definition
Status
Items
SOC indication
RUN/ALM
RemAXE
LED1
LED2
LED3
LED4
LED5
Charge
SOC
0%-25%
(t=1S)
RUN/ALM light on
and one SOC lights
flicker
26%-50%
(t=1S)
51%-75%
(t=1S)
76%-99%
(t=1S)
100%
Discharge
SOC
100%-76%
75%-51%
50%-26%
25%-5%
5%-0%
(t=1S)
RUN/ALM light
flicker
Idle
100%-76%
75%-51%
50%-26%
25%-5%
5%-0%
(t=1S)
RUN/ALM light
flicker
Parallel
connectio
n
Parallel connection
succeeds
SOC indicates current remaining
capacity
RUN/ALM light
flicker green
Protection
Cell charge overvoltage
alarm
(t=1S)
RUN/ALM light
flicker green
Cell charge overvoltage
protection
(t=1S)
RUN/ALM light
flicker green
PACK charge
overvoltage alarm
(t=1S)
RUN/ALM light
flicker green
PACK charge
overvoltage protection
(t=1S)
RUN/ALM light
flicker green
Over charge and over
discharge alarm
(t=1S)
RUN/ALM light
flicker green
Over charge and over
discharge protection
(t=1S)
RUN/ALM light
flicker green
 Charging current limit
does not respond
(t=1S)
RUN/ALM light
flicker green
 Charge and discharge
high temperature alarm
(t=1S)
RUN/ALM light
flicker green
Charge and discharge
high temperature
(t=1S)
RUN/ALM light
flicker green
