＊ Ensure to read the Guidance before installation in order to understand product
information and safety precautions.
＊ Operators should be well trained to fully understand grid-connected photovoltaic power
system and national/regional standards.
＊ Installers must use insulating tools and wear safety equipment.
＊ Device damages caused noncompliance with storage, transportation, installation and usage
requirements specified in Quick Guidance and Manual are not coved by Warranty.
1 Product Overview
LED 1
LED 2
LED 4
LED 5
LED 3
2
1
3
4
5
6
7
8
1
475
765
150
148
745
No. label Name No. label Name
1 POWER Power button 5 Link-out Parallel Network Output
2 + Positive terminal 6 Grounding terminal
3 _ Nagative terminal 7 PCS Network port to PCS
4 Link-In Parallel Network Input 8 Safety vent A vent to release pressure inside.
