Page #44 background imageLoading...
Page #44 background image
44
lower than 60°C , restart inverter, if error
message still exists, contact Growatt.
Error: 409
Bus over voltage
Restart inverter, if problem still exist,
Contact Growatt.
Error: 411
DSP communicates with M3
abnormal
Restart inverter, if problem still exist,
update the DSP&M3 firmware
Change DSP board or M3 board, if problem
still exist, contact Growatt.
Error: 414
EEPROM fault.
Restart inverter, if problem still exist,
Contact Growatt.
Error: 417
The data sampled by the DSP and
redundant M3 is not the same.
Restart inverter, if problem still exist,
Contact Growatt.
Error: 420
GFCI fault.
Restart inverter, if problem still exist,
change power board, or contact Growatt.

Other manuals for Growatt MIN 2500TL-X

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Growatt MIN 2500TL-X and is the answer not in the manual?

Growatt MIN 2500TL-X Specifications

General IconGeneral
Product colorWhite
Overvoltage categoryCAT II
Power protection featuresOver voltage, Reverse polarity, Short circuit
International Protection (IP) codeIP65
Noise level35 dB
Product type-
Maximum power2500 W
Output current13.3 A
DC input voltage500 V
Number of phases1
Output frequency50/60 Hz
Starting voltage100 V
MPP voltage range80 - 500 V
Output power capacity (max)- kVA
Input operation voltage (min)80 V
Output operation voltage (max)280 V
Output operation voltage (min)180 V
Operating temperature (T-T)-25 - 60 °C
Wi-FiYes
Display technologyOLED
Weight and Dimensions IconWeight and Dimensions
Depth160 mm
Width375 mm
Height350 mm
Weight10800 g
