Growatt MIN 6000TL-X User Manual

41
42
12 Manufacturer Warranty
Please refer to the warranty card.
13 Decommissioning
13.1 Dismantling the Inverter
13.2 Packing the Inverter
1. Disconnect the inverter as described in section8.
2. Remove all connection cables from the inverter.
3. Screw off all projecting cable glands.
4. Lift the inverter off the bracket and unscrew the bracket screws.
CAUTION
Danger of burn injuries due to hot enclosure parts!
Wait 20 minutes before disassembling until the housing has cooled down.
If possible, always pack the inverter in its original carton and secure it with tension belts.
If it is no longer available, you can also use an equivalent carton. The box must be
capable of being closed completely and made to support both the weight and the size of
the inverter.
13.3 Storing the Inverter
Store the inverter in a dry place where ambient temperatures are always between -25°C
and +60°C.
13.4 Disposing of the Inverter
Do not dispose of faulty inverters or accessories together with household
waste. Please accordance with the disposal regulations for electronic waste
which apply at the installation site at that time. Ensure that the old unit and,
where applicable, any accessories are disposed of in a proper manner
14.1 Specification
Technical Data 14
Model
Specifications
2500TL-X 3000TL-X 3600TL-X 4200TL-X
Input data(DC)
Max. recommended PV
power(for module STC)
Max. DC voltage
Start voltage
Nominal voltage
MPP voltage range
MPP voltage range at Full
Power
No. of MPP trackers
No. of PV strings per
MPP trackers
Max. input current per
MPP trackers
Max. short-circuit current
per MPP trackers
DC overvoltage category
Output data(AC)
AC nominal power
Max. AC apparent power
Nominal AC voltage/range*
AC grid frequency/range
Max. output current
Inrush current
Max output fault current
Backfeed current
Max output overload
protection
P o w e r f a c t o r ( @ n o m i n a l
power)
3500W
500V
550V
100V
360V
4200W 5040W 5880W
80-500
80-500
80-550
80-550
100V-450V 120V-450V 150V-500V 170V-500V
2
1
12.5A
16A
Category II
2.5kW
3kW
3.6kW
4.2kW
2.5kVA
3kVA 3.6kVA
4.2kVA
230/
160~300V
50-60Hz/44-55Hz;54-65Hz
11.3A 13.6A 16A 19A
<10A
53A
16A 16A 20A 25A
0A
>0.99
230/
160~300V
230/
160~300V
230/
160~300V

Growatt MIN 6000TL-X Specifications

General

Purpose	Solar panel
Efficiency	98.4 %
Input current	27.2 A
Input voltage	80 - 500 V
Output current	16 A
Output voltage	100 V
Input frequency	50/60 Hz
Power supply type	Indoor
Power current type	DC1-to-DC2
Maximum input power	6000 W
Maximum input voltage	500 V
Output power capacity	6 kVA
Quantity per pack	1 pc(s)
Product color	White

Weight and Dimensions

Depth	350 mm
Width	375 mm
Height	160 mm
Weight	10800 g
