Growatt MIN 8000TL-XE - Size and Weight; Storage of Inverter

16
3.3 Size and weight
Dimensions and weight
Model
Height (H)
Width (W)
Depth (D)
Weight
7000-10000TL-X
425mm 16.7inch
392mm 15.4inch
180mm 7.1inch
18.2kg
3.4 Storage of Inverter
If you want to storage the inverter in your warehouse, you should choose an
appropriate location to store the inverter.
 The unit must be stored in original package and desiccant must be left in the
package.
 The storage temperature should be always between -25℃and +60℃. And the
storage relative humidity can achieve to 100%.
 If there are a batch of inverters need to be stored, the maximum layers for original
carton is four.
 After long term storage, local installer or service department of GROWATT
should perform a comprehensive test before installation.
425
392
180
Rating
Operation Ambient
temperature
-25...+60℃ (-13...+ 140°F)
with derating above 45°C（113°F）
