Growatt MOD 10KTL3-X User Manual

37
38
9.3.5 Check firmware version,Region,Country/Area and Power Quality Response
Modes (Australia model only)
The inverter power output will vary in response to the AC grid voltage. This is switched
on by default.This function belongs to advanced function, if you need to change, please
contact the after-sales operation and maintenance to make adjustments.
Reset Country
Country/Aera
VDE0126
Country/Aera
xxxxxxx
Set OK
Set parameter
General
Advanced
Password
***
Reset Region
Set Region
A B C
NO
YES
Set OK
Set parameter
General
Advanced
Password
***
Reset PQRM
Set PQRM
Volt-Var
Set PQRM
xxxxxxx
Set OK
Set parameter
General
Advanced
Password
***
Set Region
A B C
Country/Aera
Australia
Set PQRM
Disable Enable
9.3.6 Generation & Export limitation control and Power Sensor setting
(Australia model only)
Single touch to switch display or make the number +1.
Double touch to confirm you setting.
Control type:
SW stands for enabling software limit control function
HW stands for enabling hardware limit control function
Both stands for enabling software and hardware limit control function at the same time.
Generation limit
OFF ON
Control type
SW HW Both
Set OK
Set parameter
General
Advanced
Password
***
Limit Rate
XXX.X%
Export limit
OFF ON
Meter
CT
Limit Rate
XXX.X%
Set parameter
General
Advanced
Password
***
Control type
SW HW Both
Set OK

Growatt MOD 10KTL3-X Specifications

General

Max. DC Voltage	1100 V
Nominal AC Power Output	10000 W
Max. AC Apparent Power	11000 VA
Number of MPP Trackers	2
Max. Input Current per MPP Tracker	16 A
Operating Temperature Range	-25°C to +60°C
IP Rating	IP65
Max. DC Power	13000 W
Start Voltage	180 V
Nominal DC Voltage	600 V
Number of DC Inputs per MPPT	2
Max. AC Current	16 A
Nominal Grid Frequency	50/60 Hz
THDI	<3%
DC Switch	Yes
Protection Class	Class I
Topology	Transformerless
Efficiency	98.3%
Noise Level	<30 dB
Cooling Method	Natural Convection
MPPT Voltage Range	160 V to 1000 V
Nominal AC Voltage	230/400 V
Power Factor	0.8 leading ... 0.8 lagging
Communication	RS485 / WiFi / Ethernet
AC Voltage Range	310 V - 480 V
