Growatt MOD 10KTL3-X User Manual

Index
1 Notes on this manual
2 Safety
3 Product overview
3.1 Appearance overview
3.2 Dimensions
3.3 Storage environment
1.1 Validity
1.2 Applicable personnel
1.3 Symbols in this document
2.1 Product description and features
2.2 Qualification of skilled person
2.3 Safety instruction
4 Unpacking inspection
5 Installation
5 1 Basic installation requirements.
5.2 Mounting wall mount
5.3 Installing the inverter
6.1 Security
6.2 AC side wiring
6.3 DC side wiring
6.4 Connect the signal cable
6.5 Grounding the inverter
6.6 Active power control with smart
meter,CT or ripple control signal
receiver
6.7 GFCI(Standard)
6.8 Inverter demand response modes
(DRMS)
6.9AFCI(Optional)
6 Inverter wiring

Growatt MOD 10KTL3-X Specifications

General

Max. DC Voltage	1100 V
Nominal AC Power Output	10000 W
Max. AC Apparent Power	11000 VA
Number of MPP Trackers	2
Max. Input Current per MPP Tracker	16 A
Operating Temperature Range	-25°C to +60°C
IP Rating	IP65
Max. DC Power	13000 W
Start Voltage	180 V
Nominal DC Voltage	600 V
Number of DC Inputs per MPPT	2
Max. AC Current	16 A
Nominal Grid Frequency	50/60 Hz
THDI	<3%
DC Switch	Yes
Protection Class	Class I
Topology	Transformerless
Efficiency	98.3%
Noise Level	<30 dB
Cooling Method	Natural Convection
MPPT Voltage Range	160 V to 1000 V
Nominal AC Voltage	230/400 V
Power Factor	0.8 leading ... 0.8 lagging
Communication	RS485 / WiFi / Ethernet
AC Voltage Range	310 V - 480 V
