Growatt MOD 10KTL3-X User Manual

8.1 Normal mode
8.2 Failure mode
8.3 Shutdown mode
13 1 Error message.
13 2 Syetem error.
17 1 Specification.
17 2 Torque.
17 3 Annex.
15.1 Dismantling the inverter
15.2 Packing the inverter
15.3 Storing the inverter
15.4 Disposing of the inverter
13 Troubleshooting
8 Working mode
14 Manufacturer warranty
15 Decommissioning
17 Specification
16 EU declaration of conformity
18 EU declaration of conformity
9.1 Boot display
9.2 OLED display wake up
9.3 Function setting
12.1 Start the inverter
12.2 Shut down the inverter
9 OLED display and touch
buttons
19 Contect us
12 Start the inverter and shut
down the inverter
10 Communication and
monitoring
11 Maintenance and Cleaning
10.1 RS485
10.2 USB-A
11.1 Checking heat dissipation
11.2 Cleaning the inverter
11.3 Checking the DC disonnect
7 Debugging

Growatt MOD 10KTL3-X Specifications

General

Max. DC Voltage	1100 V
Nominal AC Power Output	10000 W
Max. AC Apparent Power	11000 VA
Number of MPP Trackers	2
Max. Input Current per MPP Tracker	16 A
Operating Temperature Range	-25°C to +60°C
IP Rating	IP65
Max. DC Power	13000 W
Start Voltage	180 V
Nominal DC Voltage	600 V
Number of DC Inputs per MPPT	2
Max. AC Current	16 A
Nominal Grid Frequency	50/60 Hz
THDI	<3%
DC Switch	Yes
Protection Class	Class I
Topology	Transformerless
Efficiency	98.3%
Noise Level	<30 dB
Cooling Method	Natural Convection
MPPT Voltage Range	160 V to 1000 V
Nominal AC Voltage	230/400 V
Power Factor	0.8 leading ... 0.8 lagging
Communication	RS485 / WiFi / Ethernet
AC Voltage Range	310 V - 480 V
