Growatt MOD 10KTL3-X User Manual

51
52
EU Declaration of conformity 16
With the scope of EU directives:
•2014/35/EU Low Voltage Directive (LVD)
•2014/30/EU Electromagnetic Compatibility Directive (EMC)
•2011/65/EU RoHS Directive and its amendment (EU)2015/863
Shenzhen Growatt New Energy Technology Co. Ltd confirms that the Growatt inverters
and accessories described in this document are in compliance with the above mentioned
EU directives. The entire EU Declaration of Conformity can be found at www.ginverter.com.
17.1 Parameter
Specification 17
Model
Specifications
MOD
3000TL3-
X
MOD
4000TL3-
X
MOD
5000TL3-
X
MOD
6000TL3-
X
MOD
7000TL3-
X
MOD
8000TL3-
X
Input data(DC)
Max. recommended PV
power(for module STC)
4500W
6000W
7500W
9000W
10.5kW
12kW
Max. DC voltage
1100V
Start voltage
200V
Min. operating voltage
140V
Nominal voltage
580V
MPP voltage range
140-1000V
No. of MPP trackers
2
No. of PV strings per MPP
trackers
1/1
1/1
1/1
1/1
1/1
1/1
Max. input current per MPP
trackers
13/13A
13/13A
13/13A
13/13A
13/13A
13/13A
Max. short-circuit current
per MPP trackers
16/16A
Backfeed current to PV array
0A
Output data(AC)
Rated output power
3000W
4000W
5000W
6000W
7000W
8000W
Max. AC apparent
3300VA
4400VA
5500VA
6600VA
7700VA
8800W
Nominal AC voltage/range
230/400V
AC grid frequency/range
50/60 Hz
45~55Hz/55-65 Hz
Rated apparent power
3300VA
4400VA
5500VA
6600VA
7700VA
8800VA
Max. output current
5.0A
6.7A
8.3A
10.0A
11.7A
13.3A
Max output overload
protection
50A
Max. inrush current(Peak
value/duration time)
10A/5ms
AC inrush current
30A
Max. output fault
current(Peak value/duration
time)
24.6A/10us
24.6A/10us
24.6A/10us
24.6A/10us
44.5A/10us
44.5A/10us
Max. output fault current
24.6A
44.5A
Max. output overcurrent
Protection
24.6A
44.5A
Power factor(@nominal
power)
>0.99
Adjustable power factor
0.8Leading ...0.8Lagging
THDi
<3%
AC grid connection type
3W+PE /3W+N+PE
Overvoltage category
PV:II AC:III Others:I
Efficiency
Max. efficiency
98.3%
98.6%
Euro-eta
97%

Growatt MOD 10KTL3-X Specifications

General

Max. DC Voltage	1100 V
Nominal AC Power Output	10000 W
Max. AC Apparent Power	11000 VA
Number of MPP Trackers	2
Max. Input Current per MPP Tracker	16 A
Operating Temperature Range	-25°C to +60°C
IP Rating	IP65
Max. DC Power	13000 W
Start Voltage	180 V
Nominal DC Voltage	600 V
Number of DC Inputs per MPPT	2
Max. AC Current	16 A
Nominal Grid Frequency	50/60 Hz
THDI	<3%
DC Switch	Yes
Protection Class	Class I
Topology	Transformerless
Efficiency	98.3%
Noise Level	<30 dB
Cooling Method	Natural Convection
MPPT Voltage Range	160 V to 1000 V
Nominal AC Voltage	230/400 V
Power Factor	0.8 leading ... 0.8 lagging
Communication	RS485 / WiFi / Ethernet
AC Voltage Range	310 V - 480 V
