Growatt MOD 10KTL3-X User Manual

57
58
Model
Specifications
MOD
3000TL3-
X
MOD
4000TL3-
X
MOD
5000TL3-
X
MOD
6000TL3-
X
MOD
7000TL3-
X-AU
MOD
8000TL3-
X-AU
Protection devices
DC reverse-polarity
protection
YES
DC switch
YES
DC Surge protection
typeII OPT
Insulation resistance
monitoring
YES
AC surge protection
typeII OPT
AC short-circuit
protection
YES
Grid monitoring
YES
Anti-islanding protection
Integrated(ActiveFrequencyDrift)
Residual-current
monitoring unit
YES
String Fuse protection
NO
String monitoring
OPT
AFCI protection
OPT
General data
Dimensions (W / H / D) in
mm
425*387*147mm
425*387* 178mm
Weight
12.5kg
16.0kg
Operating temperature
range
-25°C ... +60°C
(>45°CDerating)
Noise emission (typical)
≤35dB(A)
Altitude
4000m
Internal consumption at
night
1W
Topology
Non-isolated
Cooling
Natural heat dissipation
Electronics protection
degree
IP66
Relative humidity
0~100%
DC connection
H4/MC4(OPT)
AC connection
Waterproof PG head+OT terminal or quick connect terminal
Interfaces
Display
OLED+LED
USB/RS485
YES
WIFI/GPRS/4G/RF/LAN
OPT
Model
Specifications
MOD
9000TL3-
X-AU
MOD
10KTL3-X-
AU
MOD
11KTL3-
X-AU
MOD
12KTL3-X
MOD
13KTL3-X
MOD
15KTL3-X
Input data(DC)
Max. recommended PV
power(for module STC)
13.5kW
15kW
16.5kW
18kW
19.5kW
22.5kW
Max. DC voltage
1100V
Start voltage
200V
Nominal voltage
580V
MPP voltage range
140-1000V
Full-load voltage range
320-850V
400-850V
480-850V
520-850V
No. of MPP trackers
2
No. of PV strings per MPP
trackers
1/2
1/2
1/2
1/2
1/2
1/2
Max. input current per MPP
trackers
13/26A
13/26A
13/26A
13/26A
13/26A
13/26A
Max. short-circuit current
per MPP trackers
16/32A
16/32A
16/32A
16/32A
16/32A
16/32A
Backfeed current to PV array
0A
Output data(AC)
Rated output power
9000W
10kW
11kW
12kW
13kW
15kW
Max. AC apparent
9000VA
10kVA
11kVA
12kVA
13kVA
15kVA
Rated apparent power
9000VA
10kVA
11kVA
12kVA
13kVA
15kVA
Nominal AC voltage/range
230/400V
AC grid frequency/range
50/60 Hz
45~55Hz/55-65 Hz
Rated output current
13.6A
15.2A
16.7A
18.2A
19.7A
22.7A
Max. output current
13.6A
15.2A
16.7A
18.2A
19.7A
22.7A
Max output overload
protection
63A
Max. inrush current(Peak
value/duration time)
10A/5ms
15A/5ms
AC inrush current
30A
Max. output fault
current(Peak value/duration
time)
44.5A/10us
58.4A/10us
Max. output fault current
44.5A
58.4A
Max. output overcurrent
Protection
44.5A
58.4A
Power factor(@nominal
power)
>0.99
Adjustable power factor
0.8Leading ...0.8Lagging
THDi
<3%
AC grid connection type
3W+PE /3W+N+PE
Overvoltage category
PV:II AC:III Others:I
Efficiency
Max. efficiency
98.6%
Euro-eta
97%

Growatt MOD 10KTL3-X Specifications

General

Max. DC Voltage	1100 V
Nominal AC Power Output	10000 W
Max. AC Apparent Power	11000 VA
Number of MPP Trackers	2
Max. Input Current per MPP Tracker	16 A
Operating Temperature Range	-25°C to +60°C
IP Rating	IP65
Max. DC Power	13000 W
Start Voltage	180 V
Nominal DC Voltage	600 V
Number of DC Inputs per MPPT	2
Max. AC Current	16 A
Nominal Grid Frequency	50/60 Hz
THDI	<3%
DC Switch	Yes
Protection Class	Class I
Topology	Transformerless
Efficiency	98.3%
Noise Level	<30 dB
Cooling Method	Natural Convection
MPPT Voltage Range	160 V to 1000 V
Nominal AC Voltage	230/400 V
Power Factor	0.8 leading ... 0.8 lagging
Communication	RS485 / WiFi / Ethernet
AC Voltage Range	310 V - 480 V
