9.3.5 Check firmware version,Region,Country/Area and Power Quality Response
Modes (Australia model only)
The inverter power output will vary in response to the AC grid voltage. This is switched
on by default.This function belongs to advanced function, if you need to change, please
contact the after-sales operation and maintenance to make adjustments.
Reset Country
Country/Aera
VDE0126
Country/Aera
xxxxxxx
Set OK
Set parameter
General
Advanced
Password
***
Reset Region
Set Region
A B C
NO
YES
Set OK
Set parameter
General
Advanced
Password
***
Reset PQRM
Set PQRM
Volt-Var
Set PQRM
xxxxxxx
Set OK
Set parameter
General
Advanced
Password
***
Set Region
A B C
Country/Aera
Australia
Set PQRM
Disable Enable
9.3.6 Generation & Export limitation control and Power Sensor setting
(Australia model only)
Single touch to switch display or make the number +1.
Double touch to confirm you setting.
Control type:
SW stands for enabling software limit control function
HW stands for enabling hardware limit control function
Both stands for enabling software and hardware limit control function at the same time.
Generation limit
OFF ON
Control type
SW HW Both
Set OK
Set parameter
General
Advanced
Password
***
Limit Rate
XXX.X%
Export limit
OFF ON
Meter
CT
Limit Rate
XXX.X%
Set parameter
General
Advanced
Password
***
Control type
SW HW Both
Set OK

Growatt MOD 15KTL3-X Specifications

General

Product type	-
Maximum power	15000 W
Output current	25 A
DC input voltage	1100 V
Output frequency	50/60 Hz
MPP voltage range	140 - 1000 V
Output power capacity (max)	15 kVA
Input operation voltage (min)	160 V
Maximum input current per MPPT	26 A
Output operation voltage (max)	440 V
Output operation voltage (min)	340 V
Total Harmonic Distortion (THD)	3 %
Number of maximum power point tracking (MPPT)	2
Wi-Fi	Yes
Operating temperature (T-T)	-25 - 60 °C
Display technology	OLED
Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Short circuit
International Protection (IP) code	IP66

Weight and Dimensions

Depth	178 mm
Width	425 mm
Height	387 mm
