Growatt MOD 15KTL3-X User Manual

Set Language
English
Exporlimit
Set Country
VDE0126
AUTO TEST
Set paramerter
Reset factory
Set Time
12:30:30
Set Date
2018-12-14
Set Comaddr
1
Set Language
English
Double touch
Set Date
2018-12-14
Set Date
2018-12-14
Set Date
2018-12-14
Set OK
Set Time
12:30:00
Set Time
12:30:00
Set Time
12:30:00
Set OK
Fig 9.5
9.3.10
Under the permission given by your energy provider, the ratio of your system output
power divided by the rated power of the inverter is called Limit Rate.For instance,if the
energy provider only accepts 8kVA/kW from your 10kW system, then the Limit Rate of
10kW inverter is 80.0%.
Fig 9.4
Fig 9.5
9.3.7 Set language
The default language is English,touch twice in a row to enter the setting mode,a single
touch to switch the language, and touch twice to confirm the setting.
9.3.8 Set COM address
The default COM address is 1.Touch twice in a row to enter the setting mode, single
touch, the number +1,touch twice in a row to confirm the setting,long press for 5S
number to return to zero.
Reset factory
AUTO TEST
Set paramerter
Set language
Set Date
2018-12-14
Set Time
12:30:00
Exportlimit
Set Comaddr
1
9.3.9 Set date and time
Touch twice to enter the parameter setting submenu, select the general setting,touch
twice to enter the general setting submenu, single touch to switch the display interface,
touch twice in the date and time interface to enter the setting state,single touch,number
+.
Language
English
Language
XXXX
Set
successfully
40
39

Growatt MOD 15KTL3-X Specifications

General

Product type	-
Maximum power	15000 W
Output current	25 A
DC input voltage	1100 V
Output frequency	50/60 Hz
MPP voltage range	140 - 1000 V
Output power capacity (max)	15 kVA
Input operation voltage (min)	160 V
Maximum input current per MPPT	26 A
Output operation voltage (max)	440 V
Output operation voltage (min)	340 V
Total Harmonic Distortion (THD)	3 %
Number of maximum power point tracking (MPPT)	2
Wi-Fi	Yes
Operating temperature (T-T)	-25 - 60 °C
Display technology	OLED
Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Short circuit
International Protection (IP) code	IP66

Weight and Dimensions

Depth	178 mm
Width	425 mm
Height	387 mm
