GRS GraverSmith 004-895 - Page 10

022-230
022-948
044-006
004-951
044-161
022-965
022-965
022-965
044-157
044-160
044-158
023-051
022-230
022-230
044-159
024-169
024-170
044-255
024-168
002-536
022-230
022-230
GraverSmith™ Pneumatic Parts List
002-536 NUT, 1/4"-20 FLNG LOCK Z/P
004-951 VALVE BODY, ROTARY
022-230 FITTING, PTC 0.25" 90° M1/8" NPT
022-948 O-RING, 1.078" O.D. 0.938" I.D.
022-965 FITTING, PTC 0.25" BULKHEAD
023-051 ARG REGULATOR GAUGE IN KNOB
024-167 MOLDED AIR TANK (TWO HOLE VERSION) - 1
024-168 SPECIAL WASHER - 3
024-169 O-RING - 1
024-170 SOCKET HEAD CAP SCREW - 3
044-006 VALVE SHROUD, ROTARY
044-157 6.0" LENGTH OF 050-029
044-158 8.8" LENGTH OF 050-002
044-159 8.6" LENGTH OF 050-002
044-160 12.60" LENGTH OF 050-002
044-161 10.6" LENGTH OF 050-002
