Grundfos CR 10 Instructions

English (GB)
5
English (GB) Installation and operating instructions
Original installation and operating instructions.
CONTENTS
Page
1. General information
1.1 Removing the transport bracket
When removing the transport bracket, this procedure must be followed.
If the transport bracket is not removed correctly, the pump bearings and shaft
seal may be damaged.
1. General information
5
1.1 Removing the transport bracket
5
1.2 Fitting the motor
8
Read these instructions carefully before removing the
transport bracket.
Step Action Illustration
1
Remove the coupling guards,
if fitted.
TM02 8649 0704

Grundfos CR 10 Specifications

General

Type	Centrifugal Pump
Liquid Temperature	-20°C to +120°C
System Pressure	Max 25 bar
Pump Housing	Stainless Steel
Impeller	Stainless Steel
Motor Type	Asynchronous motor
Frequency	50/60 Hz
Protection Class	IP55
Insulation Class	F
Max Head	Up to 160 m
Motor Power	0.37 kW
Approvals	CE, EAC
