Grundfos CR 10 Instructions

English (GB)
6
2
Remove three screws from
the coupling.
TM02 8650 0704
3
Slacken the last screw with a
hexagon key, but do not
unscrew it completely.
TM02 8653 0704
4
Loosen one coupling half by
gently tapping the end of the
hexagon key with the flat
hand.
TM02 8652 0704
Step Action Illustration

Grundfos CR 10 Specifications

General

Type	Centrifugal Pump
Liquid Temperature	-20°C to +120°C
System Pressure	Max 25 bar
Pump Housing	Stainless Steel
Impeller	Stainless Steel
Motor Type	Asynchronous motor
Frequency	50/60 Hz
Protection Class	IP55
Insulation Class	F
Max Head	Up to 160 m
Motor Power	0.37 kW
Approvals	CE, EAC
