Grundfos CR 10 Instructions

English (GB)
7
5
Remove the last screw and
one coupling half.
TM02 8651 0704
6
Loosen the other coupling half
by gently tapping the flat part
of it.
Remove the coupling half.
TM02 8655 0704
7 Remove the transport bracket.
TM02 8654 0704
Step Action Illustration

Grundfos CR 10 Specifications

General

Type	Centrifugal Pump
Liquid Temperature	-20°C to +120°C
System Pressure	Max 25 bar
Pump Housing	Stainless Steel
Impeller	Stainless Steel
Motor Type	Asynchronous motor
Frequency	50/60 Hz
Protection Class	IP55
Insulation Class	F
Max Head	Up to 160 m
Motor Power	0.37 kW
Approvals	CE, EAC
