Technical data
61
1)
Weights are based on pump with TEFC motor (see price list for individual weights)
All dimensions in inches unless otherwise noted.
TM02 7701 1009
Pump type
P2
[hp]
Ph.
Dimensions [inch]
Ship Wt.
[lbs.]
Dimensions [inch]
Ship Wt.
[lbs.]
B1
TEFC ODP MLE
D1 D2 B1+B2 D1 D2 B1+B2 D1 D2 B1+B2
CR(E) 64-1-1 10
1 22.09 10.23 10.30 38.16 - - - 268 - - - -
3 22.09 8.66 5.28 37.60 - - - 252 10.24 8.39 37.01 274
CR(E) 64-1 15 3 26.42 10.22 8.67 43.00 10.62 7.33 42.73 377 13.39 12.13 45.20 533
CR 64-2-2 20 3 29.69 10.22 8.67 46.27 11.50 8.92 49.38 392 - - - -
CR(E) 64-2-1 20 3 29.69 10.22 8.67 46.27 11.50 8.92 49.38 392 13.39 12.13 48.47 564
CR(E) 64-2 25 3 29.69 12.94 11.52 49.51 11.50 8.94 50.50 438 13.39 12.13 52.41 593
CR(E) 64-3-2 30 3 32.91 15.32 13.11 56.10 11.50 8.94 54.72 609 13.39 12.13 55.63 664
CR 64-3-1 40 3 32.91 15.32 13.11 56.10 13.25 12.21 56.16 624 - - - -
CR 64-3 40 3 32.91 15.32 13.11 56.10 13.25 12.21 56.16 624 - - - -
CR 64-4-2 40 3 36.18 15.32 13.11 59.37 13.25 12.21 59.43 624 - - - -
CR 64-4-1 50 3 36.18 16.88 14.12 63.99 13.25 12.21 58.93 676 - - - -
CR 64-4 50 3 36.18 16.88 14.12 63.99 13.25 12.21 58.93 676 - - - -
CR 64-5-2 60 3 39.41 19.00 14.90 70.20 15.12 13.19 65.54 866 - - - -
CR(E) 64

Grundfos CRI Series Specifications

General

Protection Class	IP55
Insulation Class	F
Material	Stainless Steel
Applications	irrigation
Temperature range	+120 °C
Motor range	0.37 kW
Impeller Material	Stainless Steel
Connections	Flanged or threaded
Seal Type	Mechanical seal
