Grundfos CRI Series - ODP Motors; 2 Pole MLE Motors

Motor data
CR, CRI, CRN, CRE, CRIE, CRNE
73
ODP motors
(Open Drip Proof, constant speed)
2 Pole MLE motors
(Integrated variable frequency drive)
HP PH
ODP
Frame
ODP
S.F.
ODP
Voltage
ODP
Mtr.
Eff. %
ODP
Insul.
class
ODP
KVA
code
ODP Full
load
current
ODP service
Factor
current
ODP
Start current
15 3 254TCZ 1.15 208-230/460 89.5 F H 37-35/17.5 40-39.4/19.7 225-248/124 Baldor motor
20 3 254TC 1.15 230/460 90.2 B G 48/24 55/27.5 306/153
TM02 7696
25 3 284TSCZ 1.15 208-230/460 91 B G 64-59/29.5 74-67/33.5 335-374/187
30 3 284TSC 1.15 230/460 91 F H 70/35 80/40 480/240
40 3 286TSCZ 1.15 230/460 91.7 F F 94/47 108/54 542/271
50 3 324TSCZ 1.15 230/460 92.4 F G 116/58 134/67 732/366
60 3 324TSCZ 1.15 230/460 93 B G 132/66 152/76 876/438
75 3 364TSCZ 1.15 230/460 93 F G 168/84 192/96 1110/555
100 3 365TSCZ 1.15 230/460 93 F G 226/113 260/130 1380/690
Hp
Short type
designation
Voltage
[V]
Ph
NEMA
frame
Size
Service
Factor
Motor
full load
efficiency
[%]
Full load
current
amps **
[A]
Service
factor
current
amps
[A]
Power
factor
Full load
speed
[rpm]
Sound
pressure
level
dB(A)
1/2 MLE71AB-2-56C-C 208-230 1 56C 1.0 71.0* 2.8 - 2.5 - 0.96 3400 63
3/4 MLE71BA-2-56C-C 208-230 1 56C 1.0 74.0* 3.9 - 3.5 - 0.97 3400 63
1 MLE80AA-2-56C-C 208-230 1 56C 1.0 76.0* 5.2 - 4.7 - 0.97 3400 62
1 MLE90CC-2-56C-G 460-480 3 56C 1.25 77.0 1.7 2.10 0.73 3500 65
1 1/2 MLE80BA-2-56C-C 208-230 1 56C 1.0 77.0* 7.5 - 6.8 - 0.97 3400 63
1 1/2 MLE90CC-2-56C-G 208-230 3 56C 1.0 82.5 4.35 - 4.05 - 0.94 3480 65
1 1/2 MLE90CC-2-56C-G 460-480 3 56C 1.15 84.0 2.2 2.50 0.83 3480 65
2 MLE90CC-2-56C-G 208-230 3 56C 1.0 84.0 5.75 - 5.25 - 0.95 3460 70
2 MLE90CC-2-56C-G 460-480 3 56C 1.15 85.5 2.7 3.10 0.87 3460 70
3 MLE90FA-2-182TC-G 208-230 3 182TC 1.0 85.5 8.3 - 7.6 - 0.95 3460 70
3 MLE90FA-2-182TC-G 460-480 3 182TC 1.15 86.5 3.7 4.30 0.91 3460 70
5 MLE112CA-2-184TC-G 208-230 3 184TC 1.0 87.5 13.8 - 13.3 - 0.94 3470 75
5 MLE112CA-2-184TC-G 460-480 3 184TC 1.15 88.5 6.1 7.00 0.92 3470 75
7 1/2 MLE132DA-2-215TC-G 208-230 3 215TC 1.0 88.5 20.0 - 18.5 - 0.94 3450 80
7 1/2 MLE132DA-2-215TC-G 460-480 3 215TC 1.15 88.5 8.9 10.3 0.94 3470 80
10 MLE132FA-2-215TC-G 460-480 3 215TC 1.15 89.5 11.6 13.4 0.93 3500 80
15 MLE160AA-2- 254TC-F 460-480 3 254TC 1.15 90.2 18.0 20.6 0.89 3500 68
20 MLE160AB-2- 256TC-F 460-480 3 256TC 1.15 90.2 24.0 27.5 0.89 3540 68
25 MLE160AC-2- 284TC-F 460-480 3 284TC 1.15 91.0 30.5 35.0 0.88 3540 70
30 MLE180AA-2- 286TC-F 460-480 3 286TC 1.15 91.0 36.5 42.0 0.88 3540 70
