Grundfos CRNE - Radio Module; Bluetooth

Motor
[kW]
3 × 380-480 V 3 x 400-480 V
1450-2200
rpm
2900-4000
rpm
3500-4000
rpm
11 • - -
15 • • -
18.5 • • -
22 • • -
26 - - •
2.3.3 Identification of the functional module
You can identify the fitted module in one of the
following ways:
Grundfos GO
You can identify the functional module in the Fitted
modules menu under Status.
Motor display
For motors fitted with the HMI 300 or 301 operating
panel, you can identify the functional module in the
Fitted modules menu under Status.
Motor nameplate
You can identify the fitted module by means of the
data on the motor nameplate.
Env.Type:
PF:
CL:
IP:
INPUT
U in:
f in: Hz
OUTPUT
n: rpm
PDS Eff
XXX
V
:
%
Variant
PB:
FM:
HMI:
CIM:
Made in Hungary
I1/1: A
P2: kW
~ V
Tamb: C
DE:
NDE:
Wgt: kg
Type:
P.N.: -V
P.C.:
OUTPUT
rpm
XXXV
:
%
Variant
PB:
FM:
HMI:
CIM:
kW
TM082851
Functional module variants:
• FM110
• FM310
• FM311
1)
1)
Without Bluetooth (BLE).
2.3.4
Identification of the operating panel
You can identify the operating panel in one of the
following ways:
Grundfos GO
You can identify the operating panel in the Fitted
modules menu under Status.
Motor display
For motors fitted with the HMI 300 or 301 operating
panel, you can identify the operating panel in the
Fitted modules menu under Status.
Motor nameplate
You can identify the operating panel by means of the
data on the motor nameplate.
Env.Type:
PF:
CL:
IP:
INPUT
U in:
f in: Hz
OUTPUT
n: rpm
PDS Eff
XXXV
:
%
Variant
PB:
FM:
HMI:
CIM:
Made in Hungary
I1/1: A
P2: kW
~ V
Tamb: C
DE:
NDE:
Wgt: kg
Type:
P.N.: - V
P.C.:
OUTPUT
rpm
XXX
V
:
%
Variant
PB:
FM:
HMI:
CIM:
kW
TM082852
Operating panel variants
• HMI 100
• HMI 101
2)
• HMI 200
• HMI 201
2)
• HMI 300
• HMI 301
2)
2)
For motors without a radio module.
