3.4 Identification
3.4.1 Nameplate
DK - 8850 Bjerringbro Denmark
Assembled in Denmark
Type
P.N.
99350755
UN
Pmax
IP
P1
Tamb max
S.N.
P.C.
°C
5
6
7
1
2
3
4
9
10
11
8
Proc.Cont.Eq.
E256250
TM072130
Pos. Description
1 Supply voltage
2 Max. power consumption
3
Maximum ambient temperature
4 Factory code
5
Production code (year and
week)
6 Serial number
7
Enclosure class according to
IEC
8 Production site
9 Markings and approvals
10
Version number and product
number
11 Product name
3.5 GENIbus
GENIbus, the Grundfos Electronics Network Intercommunications
bus, is a fieldbus developed by Grundfos to meet the need for data
transfer in all typical Grundfos motor or pump applications.
Grundfos devices with GENIbus can be wired together in networks
and integrated in automation systems. Each device on the network
must have a unique GENIbus address. GENIbus is based on the
RS485 hardware standard and typically operates at a baud rate of
9600 bits/s.
