Grundfos UP Series 200 - Winding Resistance Chart

13
English (US)
6.6 Winding resistance chart
UP dual voltage
60 Hz
[Ω] 68 ºF - 122 ºF (20 ºC - 50 ºC)
Pump type Voltage RA
1
RA
2
RS
UP 43-70
1 x 115 V 13.4 - 17.8 10.6 - 14.2 4.50 - 6.00
1 x 230 V 13.4 - 17.8 10.6 - 14.2 4.50 - 6.00
UP 43-110
1 x 115 V 4.75 - 6.20 3.85 - 5.05 2.10 - 2.75
1 x 230 V 4.75 - 6.20 3.85 - 5.05 2.10 - 2.75
UP 53-45
1 x 115 V 13.4 - 17.8 10.6 - 14.2 4.50 - 6.00
1 x 230 V 13.4 - 17.8 10.6 - 14.2 4.50 - 6.00
UP 53-46
1 x 115 V 9.4 - 11.6 7.3 - 9.1 1.6 - 2.0
1 x 230 V 9.4 - 11.6 7.3 - 9.1 1.6 - 2.0
