Ersatzteillisten und Explosionszeichnungen / Spare Parts Lists and Exploded Views CCF 23
4 -2 GRUNDIG Service
POS. NR. SACHNUMMER BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. SACHNUMMER BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
D 517 8309-701-069 Z-DIODE BZX55C5V1 TFK
D 518 8309-720-112 Z DIODE 12 C 0,5W
D 519 75990-200.81 DIODE 1N 4007
D 520 8309-720-112 Z DIODE 12 C 0,5W
D 521-523 75990-200.81 DIODE 1N 4007
D 524 8309-215-148 DIODE 1 N 4148 WW.
D 526-529 75990-200.81 DIODE 1N 4007
D 532 8309-215-148 DIODE 1 N 4148 WW.
D 542-544 8309-215-148 DIODE 1 N 4148 WW.
D 700 75954-068.25 DIODE RED MAN TSOP1736
D 801 75953-701.54 LE DIODE TLHR 4200
D 802 8309-944-411 LE DIODE TLHY 4405 BT12Z
D 803 8309-944-411 LE DIODE TLHY 4405 BT12Z
DP 819 75954-068.30 DISPLAY VFD FV722G
F 501 75954-003.23 CERAMIC RESONATOR 4MHZ
IC 101 8305-201-466 IC 4066B/ 14066BCP
IC 102 8305-201-466 IC 4066B/ 14066BCP
IC 103 8305-201-466 IC 4066B/ 14066BCP
IC 104 8305-201-466 IC 4066B/ 14066BCP
IC 105 8305-274-297 IC UPC1297CA NEC
IC 401 59852-001.00 IR EMPFAENGER TEMS5360
IC 502 8305-602-400 IC X24C00P XICOR
IC 503 8305-205-701 IC 78M05 MOT/FAI/NEC/SGS
IC 504 8305-204-341 IC LM340AT-12 NSC
IC 514 75954-015.53 IC M 38172M4-153FB
IC 599 8305-208-469 IC M38172M4-197FP MIT (C
L 101 8140-526-383 DR 0411 4,7MH 5%
L 102 8140-526-383 DR 0411 4,7MH 5%
L 103 8140-601-110 FILTER KM 10 DF
L 104 8140-601-110 FILTER KM 10 DF
L 105 19202-358.97 SPULE 10X10 */COIL
L 106 8140-526-383 DR 0411 4,7MH 5%
L 107 8140-526-383 DR 0411 4,7MH 5%
L 108 19202-638.97 OSZILLATOR-SPULE
L 109 8140-534-175 SPULE 7X7 175 FARBE 685
L 110 8140-534-175 SPULE 7X7 175 FARBE 685
L 111 19202-358.97 SPULE 10X10 */COIL
L 112 19202-358.97 SPULE 10X10 */COIL
L 113 19202-358.97 SPULE 10X10 */COIL
R 154 8792-002-159 ESTR.S6 47 KOHM LIN
WIEDERGABEPEGEL/
PLAYBACK LEVEL
R 155 8792-002-159 ESTR.S6 47 KOHM LIN
WIEDERGABEPEGEL/
PLAYBACK LEVEL
R 156 8792-002-159 ESTR.S6 47 KOHM LIN
WIEDERGABEPEGEL/
PLAYBACK LEVEL
R 157 8792-002-159 ESTR.S6 47 KOHM LIN
WIEDERGABEPEGEL/
PLAYBACK LEVEL
R 180
S 8701-118-033 KSW SI B 22 OHM 5%
R 184
S 8701-118-033 KSW SI B 22 OHM 5%
R 232 8792-002-154
ESTR.S6 22 KOHM LIN/KOPFSTROM
HEAD CURRENT
R 233 8792-002-154
ESTR.S6 22 KOHM LIN/KOPFSTROM
HEAD CURRENT
R 252
S 8701-118-025 KSW SI B 10 OHM 5%
R 263
S 8701-118-033 KSW SI B 22 OHM 5%
R 287
S 8766-701-041 KSW SI A 47 OHM 5%
R 295 8792-002-154 ESTR.S6 22 KOHM LIN/
FREQUENZGANG/
FREQUENCY RESPONSE
R 296 8792-002-154 ESTR.S6 22 KOHM LIN/
FREQUENZGANG/
FREQUENCY RESPONSE
R 300
S 8766-701-033 KSW SI A 22 OHM 5%
R 558 8790-050-046 ESTR.SK10-A 4,7 KOHM LIN
RECORD LEVEL
R 561 8790-050-046 ESTR.SK10-A 4,7 KOHM LIN
RECORD LEVEL
R 564 8790-050-046 ESTR.SK10-A 4,7 KOHM LIN
RECORD LEVEL
R 566 8790-050-046 ESTR.SK10-A 4,7 KOHM LIN/
BANDGESCHWINDIGKEIT/
TAPE SPEED
R 901 59713-024.00 POTENTIOMETER
S 801-818 8134-020-181 TASTSCHALTER/TACT SWITCH
SI 501
S 8315-610-026 LOET-SI.-GR 200 MA/T
SI 502
S 8315-616-205 LOET-SI.-GR 800 MA/T
T 101-108 8303-267-550 TRANS.BC 550 C
T 109 8302-202-567 TRANS BC560C SIE/PHI
T 111 8303-207-548 TRANS BC548C
T 112 8303-205-558 TRANS BC558B
T 113-116 8303-267-550 TRANS.BC 550 C
T 117-119 8303-207-548 TRANS BC548C
T 121 8303-207-548 TRANS BC548C
T 122 8303-207-548 TRANS BC548C
T 162 8303-273-327 TRANS.BC 327-25
T 163 8303-207-548 TRANS BC548C
T 164 8303-207-548 TRANS BC548C
T 165 8302-200-256 TRANS.BC 338-40
T 166 8302-200-256 TRANS.BC 338-40
T 167-169 8303-205-558 TRANS BC558B
T 171-173 8303-205-558 TRANS BC558B
T 174-178 8303-207-548 TRANS BC548C
T 179 8302-200-256 TRANS.BC 338-40
T 181 8303-273-327 TRANS.BC 327-25
T 182 8302-200-256 TRANS.BC 338-40
T 183 8303-207-548 TRANS BC548C
T 184 8303-273-327 TRANS.BC 327-25
T 185 8303-267-550 TRANS.BC 550 C
T 186 8303-267-550 TRANS.BC 550 C
T 187 8303-207-548 TRANS BC548C
T 188 8303-205-558 TRANS BC558B
T 189 8303-207-548 TRANS BC548C
T 191-195 8303-207-548 TRANS BC548C
T 200 8303-207-548 TRANS BC548C
T 201 8303-207-548 TRANS BC548C
T 210 8303-207-548 TRANS BC548C
T 500 8303-205-548 TRANS BC548B
T 501 8303-205-548 TRANS BC548B
T 506-508 8303-205-548 TRANS BC548B
T 511 8303-205-548 TRANS BC548B
T 512 8303-273-327 TRANS.BC 327-25
T 513 8303-205-548 TRANS BC548B
T 515 8303-205-548 TRANS BC548B
T 516 8303-273-327 TRANS.BC 327-25
T 517 8303-205-548 TRANS BC548B
T 518 75954-015.35 TRANS. BC 636
T 519 8303-205-548 TRANS BC548B
T 523 8303-205-548 TRANS BC548B
T 524-529 8303-205-558 TRANS BC558B
T 531 8303-205-548 TRANS BC548B
T 533 8303-205-548 TRANS BC548B
T 534 8303-205-558 TRANS BC558B
T 535 8303-205-548 TRANS BC548B
T 536 8303-205-548 TRANS BC548B
T 537 8303-205-558 TRANS BC558B
T 538 8303-205-548 TRANS BC548B
T 539 8303-205-558 TRANS BC558B
T 541 8303-205-548 TRANS BC548B
T 801-803 8303-205-548 TRANS BC548B
Btx *32700#
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Ersatzteilliste
Spare Parts List
CCF 23
AUDIO/HIFI
SACH-NR. / PART NO.: 75.7105-1051
BESTELL-NR. / ORDER NO.: G.LG 3251 SCHWARZ/BLACK
1
09 / 97
POS. NR. ABB. SACHNUMMER ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
d©
Btx *32700#
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
75710-510.51 CCF 23 SCHWARZ CCF 23 BLACK
0001.000 1 75954-068.44 BLENDE FRONT MASK FRONT
0002.000 1 75954-068.48 2 FENSTER CASSETTE WINDOW CASSETTE
0003.000 1 75954-068.47 DECKEL CASSETTE RECHTS LID CASSETTE RIGHT
0004.000 1 75954-068.49 2 TASTE VOR-/RUECKLAUF KEY FORWARD/REWIND
0005.000 1 75954-068.04 6 KNOPF, FUNKTION KNOB FUNCTION
0006.000 1 75954-068.53 FENSTER DISPLAY WINDOW DISPLAY
0007.000 1 75954-068.52 RING KNOPF RING KNOB
0008.000 1 75954-068.51 KNOPF RECORD KNOB RECORD
0009.000 1 75954-068.46 DECKEL CASSETTE LINKS LID CASSETTE LINKS
0010.000 1 59852-013.00 2 DAEMPFER DAMPER
0011.000 1 75954-068.57 4 LINSE LED LENS LED
0012.000 1 75954-068.38 2 TUER CASSETTE DOOR CASSETTE
0013.000 1 75954-068.31 4 BLATTFEDER, TUER LEAF SPRING, DOOR
0014.000 1 75954-068.39 DREHFEDER CASS. TUER TORSION SPRING CASS. DOOR
0015.000 1 75954-068.34 2 TASTE EJECT KEY EJECT
0016.000 1 75954-068.45 2 HEBEL VERRIEGELUNG LEVER LOCK
0017.000 1 75954-068.35 2 DREHFEDER 2 TORSION SPRING 2
0018.000 1 75954-068.33 2 HEBEL EJECT LEVER EJECT
0020.000 1 75954-068.50 TASTEN-SATZ FUNKTION KEY SET FUNCTION
0021.000 1 52302-210.00 KAPPE NETZTASTE CAP POWER KEY
0022.000 1 52302-250.01 LED-LINSE LED LENS
0023.000 1 52302-211.01 STOESSEL PUNCH SLIDE
0024.000
S1 75954-068.54 NETZTRAFO POWER TRANSFORMER
0027.000 1 59726-004.00 X LAUFWERK A CRF 477 TAPE DRIVE A CRF 477
0029.000 1 59726-005.00 X LAUFWERK B CRF 478 TAPE DRIVE B CRF 478
0031.000 1 75954-068.10 2 FUSS, HINTEN FOOT REAR
0033.000 1 75954-068.09 2 FUSS, VORNE FOOT FRONT
0036.000 1 75954-068.39 DREHFEDER CASS. TUER TORSION SPRING CASS. DOOR
0037.000 75954-068.03 LICHTLEITER LIGHT GUIDE
0038.000 1 75954-068.08 LOGO GRUNDIG LOGO GRUNDIG
0039.000
S1 8290-991-275 NETZKABEL KPL GWN9.17 WF MAINS CABLE CPL GWN9.17 S
0040.000 1 09666-451.00 ZUGENTLASTUNG NETZKABEL PULL-RELIEF POWER CABLE
0041.000
S1 59401-042.00 NETZSCHALTER POWER SWITCH
0042.000
S 29303-452.02 NETZSTECKER-UNTERTEIL KPL MAINS PLUG LOWER PART
0044.000 1 09623-449.00 CINCHBUCHSE 4-FACH CINCH SOCKET 4 FOLD
0045.000 09641-146.01 HIFI STEREO-TONKABEL HIFI STEREO AUDIO CABLE
72010-756.25 BEDIENUNGSANLEITUNG INSTRUCTION MANUAL
D/GB/F/I/P/E/NL/DK/S/FIN D/GB/F/I/P/E/NL/DK/S/FIN
72010-755.65 SERVICE MANUAL D/GB SERVICE MANUAL D/GB
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
POS. NR. SACHNUMMER BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. SACHNUMMER BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 515
S 8660-197-042 SI-KERKO.A 3300PF 20%
C 522 8452-996-153 ELKO 3300UF 20% 25V
D 101-109 8309-215-148 DIODE 1 N 4148 WW.
D 111 8309-215-148 DIODE 1 N 4148 WW.
D 112 8309-720-091 Z-DIODE 9,1 C 0,5W
D 113 8309-215-148 DIODE 1 N 4148 WW.
D 114 8309-215-148 DIODE 1 N 4148 WW.
D 200 8309-215-148 DIODE 1 N 4148 WW.
D 210 8309-215-148 DIODE 1 N 4148 WW.
D 220 8309-215-148 DIODE 1 N 4148 WW.
D 504-508 8309-215-148 DIODE 1 N 4148 WW.
D 509 8309-720-043 Z DIODE 4,3 C 0,5W
D 511 75954-039.30 Z-DIODE BZX55-C3V9
D 512 8309-720-043 Z DIODE 4,3 C 0,5W
D 513-515 8309-198-042 DIODE TYP5 BAT42
