12 /52EN
Refrigerator / User Guide
12
Installation
In order to adjust the doors vertically,
•Loosen the fixing nut at the bottom
•Screw adjusting nut (CW/CCW)
according to the position of the door
•Tighten the fixing nut for the final
position
In order to adjust the doors horizontally,
• Loosen the fixing screw at the bottom
• Loosen the fixing bolt on the top
• Screw the adjusting bolt (CW/CCW) on
the side according to the position of
the door
• Tighten the fixing bolt on the top for
the final position
• Tighten the fixing screw at the bottom
fixing nut
adjusting nut
adjusting bolt
fixing bolt
ayar somunu
ayar civatası
sabitleme
civatası
sabitleme somunu
