5. Vision Control Panel
30 PNEG-1717 CE Approved GSI/FFI Portable Dryer Manual
Heater Switch
1. Selects/deselects each heater.
2. ON (1) = Burner operates with fan.
3. AUTO (0/1) = Burner operates in staged batch dry cycle only.
Load Auger Switch
1. Controls the fill system and auxiliary equipment where used.
2. In all modes the load auger operates when grain level is low.
3. AUTO (0/1) = Dryer shuts down after a preset period (out of grain timer) when incoming grain flow
ceases to the dryer. Timer disabled in MANUAL.
Unload Switch
1. Operates the unload system and auxiliary equipment where used.
2. MANUAL (1) = Metering rolls run in single speed only.
3. AUTO (0/1) = Metering rolls in variable speed mode (moisture control).
Outside Light Switch
1. AUTO (0/1) = Light OFF when dryer shuts down.
Start Switch
1. Starts the dryer subject to other switch settings.
Stop Switch
1. Stops all dryer functions.
2. Resets control following fault related shut down.
