7. Vision Test Firing
34 PNEG-1717 CE Approved GSI/FFI Portable Dryer Manual
Figure 7A NG Pipe Train
Figure 7B NG Supply Pipe Train
Watch gauge for pressure
Throughput adjuster
Low-Fire needle valve
Pressure regulator
(High-Fire)
High pressure switch
Watch gauge for pressure
Supply line ball valve
Regulator
